Home > Manufacturing & Processing Machinery > Paper Machinery > Paper Making Machine > Foundrinier Muti-cylinder Corrugated Paper-making Machine

Foundrinier Muti-cylinder Corrugated Paper-making Machine

Name: Foundrinier Muti-cylinder Corrugated Paper-making Machine
Brand: xinhe
SKU: 120894375

Foundrinier Muti-cylinder Corrugated Paper-making Machine thumbnail-1

Foundrinier Muti-cylinder Corrugated Paper-making Machine thumbnail-2

Foundrinier Muti-cylinder Corrugated Paper-making Machine thumbnail-3

Foundrinier Muti-cylinder Corrugated Paper-making Machine photo-1

Foundrinier Muti-cylinder Corrugated Paper-making Machine photo-2

Foundrinier Muti-cylinder Corrugated Paper-making Machine photo-3

US$ 450000.00 - 450000.00 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Product Type:

Toilet Tissue

Processing Type:

Printing Machine

Contact Supplier Request Quote Chat Now

Shandong Xinhe Paper-Making Engineering Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao or tianjin

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Product Type Toilet Tissue

Processing Type Printing Machine

Place of Origin Shandong, China

Brand Name xinhe

Model Number 2850/1200

Voltage 380/440V/550V

Power(W) to be confirmed

Dimension(L*W*H) to be confirmed

Weight to be confirmed

Certification CE

Warranty 12 Months

After-sales Service Provided Engineers available to service machinery overseas

2850/1200mm High-speed tissue paper machine with Crescent former

1.Basic parameters:

basis weight	11-30g/m²
reel trim	2850mm
max. gross capacity	50t/d
furnish	virgin pulp
max. operating speed	1200m/min
wire width	3050mm

Pictures for CTM

2850/1200mm High-speed tissue paper machine with Crescent former

1.Basic parameters:

basis weight	11-30g/m²
reel trim	2850mm
max. gross capacity	50t/d
furnish	virgin pulp
max. operating speed	1200m/min
wire width	3050mm

Pictures for CTM

2. Detail Configuration

1).Headbox

Headbox	Model	Type
	Cyberflow-s	Hydraulic type

2).Press section

suction press roll	design line force	90n/mm
	operating line force approx	90n/mm

3).Yankee dryer

Interior shell design	grooved with rectangular ribs and turbulence spoiler clips
nominal diameter	3660mm
shell length	3200mm
max. paper width on the dryer	2900mm
design speed	1600m/min
max. linear load	90n/mm
operating pressure (gauge)	10bar
shipping weight	40t
steam entry	front side
condensate exit	drive side

4).Reel

Max. roll diameter	2500mm
Max. winding speed	1200m/mim
Design speed for reel spools	1600m/min
Reel spool magazine	for 4 reel spools
Jumbo roll station	for 1 jumbo roll

3.Company Profile:

Our company undertakes design, manufacturing, supply, erection and commissioning of paper machines & new Pulp mill and also modernization of existing pulp mill and Paper machines on a turnkey basis. We have the necessary capabilities in project engineering, design, manufacturing and project management.

Our company has completed many large projects in many countries around Southeast Asia, Middle East and Africa as well. Our clients are worldwide. And we have a high reputation in the industry.
