XHPM-2800/130-40TPD Corrugated Paper Making Machine With Good Quality
PAPER MACHINE MAIN DATAS | |
Paper Grade |
Paperboard,high strength corrugated paper,test liner board etc |
Trimmed Width |
2800mm (Trim Width at reel) |
Basis Weight Range |
100-150GSM |
Design Speed |
160m/min |
Working Speed |
130m/min |
Design Production |
40TPD |
Gear Drive System |
AC frequency control sectional drive |
Pictures for KPM machine 1
Pictures for KPM machine 2
Final Product
Turn-key Projects and Auxiliary Systems
We can integrate the Paper Machine with a very deep experience in stock preparation supplying projects on the Turn-Key basis.
The Auxiliary systems that could be included in the projects are:
- Slitter Rewinder
- Approach Flow System
- Steam and Condensate System
- Vacuum System
- Compressed Air System
- Overhead Cranes
- Electrical Control
- DCS and QCS
- Fiber Recovery System
- Water Treatment System
- Chemical Dosing System
Stock Preparation including:
- Deinking Line
- OCC Line
- Virgin Pulp Line
- Broke Line
1.Customized projects and complete production lines designed according to customer needs.
2.Modification of existing machines with solutions to satisfy customer needs.
After-sale Service
3.The machine will be fully pre-erected at VALTEC workshop with complete on-mahine pre-piping in order to minimize mill site erection timing.
4.The machine can be supplied with the accessories using first class components.
5.We shall provide the G.A. drawing, foundation drawing and layout drawing after receiving the advance payment.
6.We have the professional installation team to provide erection/or erection supervision, commissioning, test-run and training for customer. The customer shall provide international flight ticket, local transportation vehicle, food, hotel accommodations and salary for our engineers.
7.Performance and Mechanical Guarantee shall be provided for 1 year from the successful commissioning or 1.5 years from the date of Bill of Lading.
XINHE is a China based leading project engineering company committed to provide project design, complete equipment lines, machine rebuild solutions and turn-key projects for the Pulp and Paper industry worldwide.
Thanks to the capability of our engineers to handle a project from the design to the erection and commissioning of the machines and equipments, XINHE became one of the few companies of this sector in China able to provide turn-key projects.
Headquartered in Liaocheng China, XINHE has one engineering office and two manufacturing sites located in different cities of China.
Our Advantages:
1. 20 years experiences in Paper and Pulp industry and 7 years professional export on tissue and paper machines.
2. Quick response within 12 hours
3. Flexible payment terms:
1) Payment can be paid by T/T, LC, DP, OA etc.
2) For spare parts, repeat order payment can be paid within 30 days after the day of B/L.
4. Professional team to follow up each order to guarantee the prompt services.
5. Strictly quality control in process of every order
6. Customized solution for you
7. Professional service on transportation
8. In time delivery
Q1: What is your min. capacity of tissue machine ?
A1: Min. capacity is 10 TPD, for this capacity the machine is single cylinder or fourdriner type tissue machine.
Q2: What is guarantee terms ?
A2: According to the international practice, performance and mechanical guarantee shall be for 1 year from the successful commissioning or 1.5 years from the date of bill of lading.
Q3: What is the production time ?
A3: Normally 3-4 months, it depends on the machine type and scope of supply. But we can arrange the partial shipment according to customer’s foundation construction schedule.
Q4: Do you provide the inspection report of equipments ?
A4: Yes, we shall inspect the equipment and issue the Ex-works Quality Certificate as well as the Product Inspection Report.
Q5: What is the standard packing for the machine?
A5: Normally wooden cases with fumigation. Unless otherwise specified, the equipment shall be packe in new and strong wooden cases and necessary measures shall be taken to protect the equipment from moisture, rain, rust, corrosion, shock and damages so as to make the equipment withstand, repetitious handling, loading and unloading as well as long distance ocean and inland transportation.
Q6: If OEM services available ?
A6: Yes. We can make the machines under customer’s brand and logo.
More information,please contact me.
