4800/350 paper board machine made in china
Paper product: paperboard
Basis weight: 100-300gsm
Trim width: 4800mm
Reel width: 4850mm
Wire width: 5300mm
Lip width of headbox: 5100mm
Working speed: 350m/min
Drive speed: 400m/min
Design speed: 400m/min
Crawl speed: 25m/min
Dynamic balance speed: 600m/min
Gauge: 6200mm
Drive way: AC frequency converter sectional drive
Main drive power: ~kw (subject to final design)
Capacity: 300t/d (165gsm, 95% efficiency, 22.5 hours)
Arrangement: double-layer, bottom layer height is 6.5m, right hand or left hand machine to be confirmed.
Dimension: 145500*12000*11500mm (L*W*H)
Max. package weight: 30t(Φ1500 blind hole roll with bearing)
Shandong XinHe Paper-Making Engineering Co.,Ltd
Our company is a China based leading project engineering company committed to provide project design, complete equipment lines, machine rebuild solutions and turn-key projects for the Pulp and Paper industry worldwide.
Professionally produce all kinds of fourdrinier/cylinder/multi-wire paper machine,crescent tissue machine model contract all kinds of paper-making engineering projects,sell Italian dryer of high-pressure steel material,headbox,suction touch roll,doctor and all kinds of deinking pulping equipments,sell and serve Italian whole set paper-making engineering project.
1) The quality control in our factory is very strict.
2) We take strong attention to every detail in the manufacturing process.
3) All the machine must be checked out ,then deivered to our customer.
4) Assembly parts were assembled well in the workshop the frame was delivered by a whole.
