echnical parameters:
| Plate area | 100X150*10mm |
| Worktable largest size | 200X180mm |
| Max printing diameter | DIM90mm |
| Max printing speed | 1000pcs/hr |
| Air consumption | 104litre/min(6bar) |
| Power | 110/220V 60/50Hz 50W |
| Dimensions | 80*75*138cm(LXWXH) |
| Weight | 175Kg |
if ink cup system
| ink cup ring | D100d90H12 |
| steel plate | 100*200*0.3mm 4holeD6 dia184*86 |
Machine features:
1.microcomputer-controller, semi-automatic, utility function, and the operating procedures are flexible and reliable.
2.The hardened axle can bearing made by famous processor and the SMC Pneumatic Components from Japan are adopted to reduce the repair and maintenance.
3.The separated colloid head makes the pad printer convenient for adjusting the speed of movement back and forth.
4.Base for each inking pan can be adjusted independently at X and Y angle, with accurate chromatograph and improved production efficiency.
5.The body of the unit adopts the die-cast rack of aluminum alloy and is both portable and solid.
6.The rolls to inking, easy to install and uninstall, and convenient for cleaning
7.The pad printer is set 4-digit number auto-counter, and is convenient for recording the quantity of the printing products.
8.With self-poise oil scraper, can adjusting the thickness of steel independently, scrape oil efficiently.
9.The pad printing machine is setting the standard procedure and off-standard program, breakthrough the function of ordinary machine, unlimited program to procure ink and printing.
Machine accessories:
A copy of specification, one set of Allen key, one piece of cross Screw and straight Screw, one piece of scraper, one piece of fuse, 4 pieces of Screw for fixing pad, 1.5 meter of power line.
Application:
Applicable to other material as glass, ceramic, wood, leather, cloth, etc.
Usage:
