Help CenterTGM-100 A5 Flat Round Dual-use Hot Stamping Machine
Related Products
-
Oblique Arm CE Screen PrinterUS$ 5110.00 - 5110.00MOQ: 5 Sets -
TM-S4-PT Four Color Pad Printer With ShuttleUS$ 3312.00 - 3312.00MOQ: 5 Sets
-
TAM-IR6000 26kw Drying Machine With Infrared Ray, Drying Oven and TunnelNegotiableMOQ: 1 Set
-
TSm-1215 Manual Screen Stretching MachineUS$ 1,000 - 15,000MOQ: 1 Set
-
TM-R4 4-color Manual Raincoat T-shirt Screen Printing MachineUS$ 777 - 1,277MOQ: 1 Set
Product show:
Technical parameter:
Stamping head stroke |
53mm |
Stamping pressure range |
≤500kgf |
Stamping temperature |
20~400℃ ℃ |
Stamping speed |
1100pcs/Hr m/min |
Stamping plate size |
150 * 200 mm |
Overall dimensions |
0.87x0.81x1.69m |
Table size |
128 * 128 |
Weight |
140 kg |
Total power |
1000 W |
Features:
(1) TGM-100 pneumatic stamping machine with easy operation, stable performance, good effect on stamping.
(2) Using pneumatic pressure stamping, with a variety of plastic sheet, can plane, bevel, face and arc.
(3) With special universal adjustable workbench to facilitate adjustment;
(4) Variety of machined parts with excellent results, processing out of the object flat, smooth, no garland, the effect of coarse.
Hot stamping machine is the use of temperature (100-380 ℃) and pressure
The gold foil paper (foil) ,Film with color ,Transfer to the product
Hot stamping Features: colorful, high gloss.
Can be used for stamping paper, wood, plastic, etc.
Can use as a branding machine
Pneumatic flat, round face Hot stamping machine
Work Method:
Heating plate and stamping film Vertical imprint on the workpiece
Video:
/sdp/1963483/4/pd-6621680/12158395-2591560/TGM-100_A5_Hot_Stamping_Machine_for_Flat_round_du.html
Applications:
TGM-100 hot stamping machine is specially for printing on round glass bottles.
Packing:
We pack goods with high stander to ensure the goods not damaged on the way of transportation.
Why Choose US:
1. All the electrical components and control system are from Germany and Japan, guarantee the stable quality of the print.
2. Multi-purpose microcomputer operating panel and touch screen operation can easily achieve man-machine dialogue.
3. As high quality steel frame structure and High temperature of the lacquer that bake, so that our printer is light and solid, beautiful and practical.
Our first-class products and considerate services have won more than 80 countries, acceptance in Europe and the United States, Canada, Southeast Asia, the Middle East and other customer, and we enjoyed a high reputation in the market. We cooperate with Omron, Emerson and Ruigao light, which are the world famous enterprises.
About Our Company:
Tamprinter printing machinery group limited is one of the most professional special printer supplier of Plastic Field in China. We have supplied OEM service for the domestic counterparts since 2005. OEM products have been achieved CE certification.
Due to business expansion, Shenzhen Tamprinter printing machinery limited International trade department have been separated from the parent company in March 2013.
Key products: Pad printer, Screen printer, UV curing machine, Heat transfer machine.
Major market: America market.
Certifications:
