LC-UV-4000s3 Tubing UV Curinging Machine

LC-UV-4000s3 Tubing UV Curinging Machine photo-1
US$ 3,600 - 4,300 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, drying machine
Automatic Grade:
Semi-Automatic
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Other, drying machine
Automatic Grade Semi-Automatic
Place of Origin Guangdong, China
Brand Name Tamprinter
Model Number LC-UV-4000S3
Voltage AC 380V/ 50Hz, 3-Phase
Power(W) 5KW
Dimension(L*W*H) 2100X750X1810mm
Weight 353kg
Certification SGS
Warranty 1 Year
After-sales Service Provided Overseas third-party support available

LC-UV-4000s3 Tubing UV Curinging Machine



1. Application:


LC-UV-4000S3 Tubing UV Curinging Machine is used for flat and round surfaces UV curing, it suite for bottle surface UV ink drying solid process and flat surface UV ink drying solid process.

Such as various of UV ink, UV adhesives, UV paint curing.



2. Features:

(1) With the high efficiency UV lamp, it can finish the UV curing quickly, the high level of UV light can be adjusted, and setting the right parameters for UV curing.


(2) LED display shows the conveyor running speed, convenient to process operation.



(3) The machine body adopts the extra-thick stainless steel for hardness and durable.

(4) UV lamp and transformers which are imported from United Kingdom that fit for special ventilation design, which can be max effectiveness.

(5) It suited for different UV curing process. This series of products is different with the traditional high-power, high-power UV equipment. In order to reduce the cost and improve output for our customer.


3, Addtional In.


Packaging & Delivery
Packaging Detail: Wooden case
Delivery Time: Within 6 days after confirm payment
Payment Terms: TT/Western Union


4.Specifications:


Specifications:


Max width of Work piece

400mm

Max height of Work piece

320mm

Conveyer size of Machine Inner

400X120mm (WXH)

Bottle mouth diameter

12-24mm

Conveyer size

400mm

Output

1800~3000Pcs/Hr

Conveyer transfer speed

0-10m/min

UV lamp power

4KW

General power

5KW

Power supply

AC 380V/ 50Hz, 3-Phase

Machine dimension

2100X750X1810mm (LXWXH)

Machine weight

353kg




  Product Image:

LC-UV-4000s3 Tubing UV Curinging Machine
