TMP - 90120 - B High Precision Oblique Arm Flat Screen Printer

TMP - 90120 - B High Precision Oblique Arm Flat Screen Printer photo-1
US$ 6,713 - 6,999 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Guangdong, China
Brand Name:
Tamprinter
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Guangdong, China
Brand Name Tamprinter
Model Number TMP - 90120 - B
Usage Bill Printer, Card Printer, Cloths Printer, Label Printer, Paper Printer
Automatic Grade Semi-Automatic
Voltage 220V 50HZ
Gross Power 3.7Kw
Dimensions(L*W*H) 1800X1400X1300mm
Weight 550kg
Certification CE Certification
Warranty 1 Year
After-sales Service Provided Overseas third-party support available

TMP-90120-B  Oblique arm CE screen printer

Application
Flat Screen Printer of this series is widely used in the packaging industry (cigarette packaging, wine packaging, gift packaging and other card paper printing) trademark, calendar, oil painting, computer keyboards, paintings, iron-on transfers, credit cards, stickers, printing; also suitable for the printing of the electronics industry.



Technical  parameters

Workbench area 1000X1300mm
Max printing area 900X1200mm
Min screen size 650X700mm
Thickness of print (mm) 0-50
Source power (kw) 3.7
Rated voltage (v/hz) 220/50HZ
Printing speed (pcs/h) 400-1000
Machine size(mm) 1800X1400X1300mm
Max table height 820
weight 550kg



1 set 1200mm length squeegee holder with 1220mm length scraper.
1 set 900mm length squeegee holder with 920mm length scraper;
total 2 set



Features
(1). This screen printing machine is driven by motor drive, which is belt drive, sensitive, balanced speed, speed adjustable.
(2). Oblique arm lifting motor, frequency control, the machine runs smoothly.
(3). Blade and back blade pressure regulating device, and can be adjusted to the thickness and size of printing.
(4). Vacuum adsorption fixed printing pieces.
(5). The printing plate has up and down, left and right, before and after tuning device, which makes it  works accurate and convenient on board.
(6). Equipped with a safety device so that the oblique arm is stopped in an upper position having a reliable security.
(7). Electronic control unit centralized control by the microcomputer controller, the whole operation more simple, flexible, and easy maintenance.
