TMG-1200H glue scraper knife edge Grinding machine
Technical Parameter:
Model No. |
TMG-900 |
TMG-1200 |
Effective Grinding length(mm) |
900 |
1200 |
Rated voltage(V/Hz) |
220/50 |
220/50 |
Dimensions(LXWXH) |
1360X475X850 |
1660X475X850 |
Power(kw) |
0.18 |
0.18 |
Rotate speed(r/Min) |
1400 |
1400 |
Weight |
80 |
90 |
Application:
The machine is the auxiliary equipment that match the screen printing machine match which is used to press glue scraper knife edge grinding, in order to ensure the straightness and angle of inclination of the knife edge, thus ensuring the accuracy of the screen printing and protect the network version.
Features:
1. simple operation: manual grinding scraping, grinding scraping speed easily controlled.
2. dual-rail structure, operation smooth and flexible.
3.low power consumption and low noise.
4. small size, light weight, low transportation costs.
5. multi-angle grinding.
6. easy to maintain.
Payment Terms: L/C, Western Union, Paypal, Money Gram, Unionpay
About Us:
Tamprinter printing machinery group limited is one of the most professional special printer supplier of Plastic Field in China. We have supplied OEM service for the domestic counterparts since 2005. OEM products have been achieved CE certification.
Due to business expansion, Shenzhen Tamprinter printing machinery limited International trade department have been separated from the parent company in March 2013.
Key products: Pad printer, Screen printer, UV curing machine, Heat transfer machine.
Applications :
It mainly applies to the printing process and pre-postpress of plastic and hardware products .Our equipment is also applicable to other material as glass, ceramic, wood, leather, cloth, etc.
Involved in the industry:
Electronics, toys, gifts, clothing, stationery, cosmetics, washing products, chemicals, food, health product, pharmaceutical and packaging etc.
Advantages :
1. All the electrical components and control system are from Germany and Japan, guarantee the stable quality of the print.
2. Multi-purpose microcomputer operating panel and touch screen operation can easily achieve man-machine dialogue.
3. As high quality steel frame structure and High temperature of the lacquer that bake, so that our printer is light and solid, beautiful and practical.
Our first-class products and considerate services have won more than 80 countries, acceptance in Europe and the United States, Canada, Southeast Asia, the Middle East and other customer, and we enjoyed a high reputation in the market. We cooperate with Omron, Emerson and Ruigao light, which are the world famous enterprises.
