Corrugated Board Thin Blade Slitter & Creaser
Material Features:
1. Adopt the scheduled pressure paper feeding which is stably.
2. Adopt thin knife separate cutting (The thickness is only 1 mm.). To make sure the separate-cut corrugated board smooth and tiny, we installed with automatic and hand grinding wheel grinding to keep the blade edge sharp.
3.After slitting & creasing ,the corrugated board to accomplish the requirement. The creased trace does not arouse the trace tearing phenomenon.
Specification
Parameters |
|
Model |
|
BFY-2000 |
BFY-2500 |
||
Width of the Corrugated board |
mm |
2000 |
2500 |
Max. Speed of Paperboard |
m/min |
141 |
141 |
Slitting Blade |
pieces |
4 |
4 |
Min. Separate Cutting Width |
mm |
200 |
200 |
Min. Creasing Width |
mm |
200 |
200 |
External Diameter of Thin & Round Knife |
mm |
260 |
260 |
Thickness of Thin & Round Blade |
mm |
1 |
1 |
Power of Electrical Machinery |
kw |
4 |
4 |
Weight of Machine |
kg |
3000 |
3000 |
Overall Dimension |
mm |
2630×1791×1130 |
3050×1791×1130 |
