BLR/TPH Pressure Hose&Fitting

Name: BLR/TPH Pressure Hose&Fitting
Brand: Blue
SKU: 120850389

BLR/TPH Pressure Hose&Fitting thumbnail-1

US$ 1 - 10 MOQ: 100 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

Blue

Model Number:

BLR/TPH

Contact Supplier Request Quote Chat Now

Ningbo Blue Refrigeration Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name Blue

Model Number BLR/TPH

Type Other, VAVLE

Application Refrigeration Parts

Certification CE

BLR/TPH Pressure Hose&Fitting

BLR/TPH Pressure Hose & Fitting are widely uesd in aviation,aerospace,transportation facility,fork truck,engineering machinery ,auto,stage lift ,air,painting and other mechanical fields.

Specification

Inner Layer:Nylon Pa 12

Outer layer:Polyurethane(TPU)

Temperature:-40 to +130 ℃

Enhancementlayer:Polyester fiber (Industrial yarn)

Color available:black,blue,red,gray,orange

1.Cut the hose using proper shears,automatic or manual cutters.The cut must be perfectly square and smooth.

2.insert the sleeve on the hose with the groove towards the hose side to be assembled.

3.Push the insert inside the hose.

4.Insert the nut onto the hose

5.Make the nut slide onto the external part of the insert(flare) and push the sleeve till it covers the bottom of the free insert.

6.Assemble the hose by positioning manual pliers on the sleeve covering its whole surface.Crimp till hand pliers open automatically.A second crimping is useful to obtain a safer assembling.

Model	Color	Inner Dia. (mm)	Outer Dia. (mm)	Tolerance (mm)	Min.Bending Radius(mm)	Working Pressure (bar/psi)	Weight (g/m)
BLR/TPH02	Available on Request	2	5.9	0.1	10	45/653	30
BLR/TPH04	Available on Request	4	8.2	0.1	35	45/653	50
BLR/TPH06	Available on Request	6	10.9	0.1	35	45/653	70

Item	Model	Specification
Straight Connector	BLR/TPH-S02(B)	For DN2 Hose,ID: 2.0MM
Elbow Connector	BLR/TPH-E02(B)	For DN2 Hose,ID: 2.0MM
T Connector	BLR/TPH-T02	For DN2 Hose,ID: 2.0MM
T Connector (Middle with Nut)	BLR/TPH-T02M(B)	For DN2 Hose,ID: 2.0MM
T Connector (Side with Nut)	BLR/TPH-T02R(B)	For DN2 Hose,ID: 2.0MM
Straight Connector	BLR/TPH-S04R(B)	For DN4 Hose,ID: 4.0MM
Elbow Connector	BLR/TPH-E04(B)	For DN4 Hose,ID: 4.0MM
T Connector	BLR/TPH-T04	For DN4 Hose,ID: 4.0MM
T Connector(Middle with Nut)	BLR/TPH-T04M(B)	For DN4 Hose,ID: 4.0MM
T Connector(Side with Nut)	BLR/TPH-T04R(B)	For DN4 Hose,ID: 4.0MM
Gasket	BLR/THP-02G	(for DN2,DN4,DN6 Hose)
Needle	BLR/THP-02N	(for DN2,DN4,DN6 Hose)
Hand Crimper	BLR/MHC02A	(for DN2 Hose)
Manual Hand Crimper	BLR/MHC04A	(for DN4,DN6 Hose)
Manual Hand Crimper Kit	BLR/HHC04CKA	(for DN4,DN6 Hose)
DC Electric Hand Crimper	BLR/HHC04B	(for DN4,DN6 Hose)
DC Electric Hand Crimper Set	BLR/HHC04CKB	(for DN4,DN7 Hose)
Tube Cutter	BLR/TC02A	(for DN2,DN4,DN6 Hose)
pressure hose with fittings(two side straight)	BLR/TPHS-60	Longth:60cm Connection:Straight
pressure hose with fittings (two side straight)	BLR/TPHS-90	Longth:90cm Connection:Straight
pressure hose with fittings(two side straight)	BLR/TPHS-120	Longth:120cm Connection:Straight
pressure hose with fittings (one straight,one elbow)	BLR/TPHSE-60	Longth:60cm Connection:Elbow and Straight
pressure hose with fittings (one straight,one elbow)	BLR/TPHSE-90	Longth:90cm Connection:Elbow and Straight
pressure hose with fittings (one straight,one elbow)	BLR/TPHSE-120	Longth:120cm Connection:Elbow and Straight
pressure hose with fittings(two side straight)	BLR/TPHE-60	Longth:60cm Connection:Elbow
pressure hose with fittings(two side straight)	BLR/TPHE-90	Longth:90cm Connection:Elbow
pressure hose with fittings(two side straight)	BLR/TPHE-120	Longth:120cm Connection:Elbow
