2000kw Turbo Electric Power Generator Set

Specifications

HL2000kw MTU Diesel Generating Set Technical Data

Specification of genset

Genset model:HL2000GF

Prime power: 2000KW/2500KVA

Standby power: 2200KW/ 2750KVA

Power factor: 0.8

Rated Voltage: 400/230V

Rated frequency (HZ): 50

Dimensions (mm) (L×W×H): 8000×2600×2700

Weight (kg): 17420

Specification of diesel engine

Engine Model: 20V4000G23

Manufacturer: MTU

Governor: ECM

Air intake way: Turbo-charged

Cylinders/Arrangement: 20/V

Bore× Stroke(MM): 170×210

Fuel Consumption Rate(L/h): 195

Lubricating oil capacity(L): 390

Coolant capacity (L): 795

Engine speed (rpm): 1500

Max Power (kW): 2420

Starting Method: DC24V electrical starting

Specification of alternator

Alternator model: HLF2000

Connecting Type: 3 Phase and 4 Wires

Number of Bearing: 1

Protection Grade: IP21

Altitude: ≤1000m

Exciter Type: Brushless, Self-exciting, AVR automatic voltage regulating,100% Copper winding wire

Insulation Class: H

Telephone Influence Factor (TIF):≤50

Voltage Regulation, Steady State: ≤±1%

Transient State Voltage: ≤-15%~+20%

Control System

Operating temperature: -20°C~60°C

Relative Humidity: 95%

Operating voltage: DC24V (range: 18-30V, pressure: 50V/5 mm )

Standard functions: Engine Control/Generator Monitoring/Generator Protection/

Engine Monitoring/Clear Text Display

Shutdown: Loss of Speed Signal,Alternator Under / Over Voltage,Alternator Under/ Over Frequency,

Mains Under / Over Voltage,Mains Under/ Over Frequency,Under / Over Speed,Low Oil Pressure,High Engine Temperature,Phase Sequence Electrical (Option),Earth Fault (Option)

Warning: Alternator Under / Over Voltage,Alternator Under/ Over Frequency,Mains Under / Over Voltage,Mains Under/ Over Frequency,Under / Over Speed,Low Oil Pressure Pre-Alarm,High Engine Temperature Pre-Alarm,High/Low Battery Voltage,Over-current,Periodic maintenance
