Specifications
- High voltage diesel generator- 6300V/10500V
- IWS Cummins engine ,100% Copper Wire alternator
large capacity emergency generator set 1500KW
Genset :
Model: HL1500GF
Prime Power (KVA / KW): 1875/1500
Standby Power (KVA / KW): 2062.5/1650
Rated Ammeter (A): 2700
Dimensions (mm) (L×W×H): 6400×2260×2625
Net Weight (kg): 12700
Engine:
Model: QSK60-G3
Number of cylinders: 16
Aspiration: Turbocharged
Bore×Store(mm):159x 159
Compression ratio: 14.9:1
Displacement, total (L): 60.2
Speed Governor: Electronic
Cooling System: Forced Water Cooling Cycle
Fuel Consumption at 100% Load (L/h): 370
Starting Method: DC24V electrical starting
Alternator:
Xingnuo, Engga, 3 Phase and 4 Wires, 100% copper wire Brushless, Self-exciting, IP23, and Insulation Class: H
Control System:
DeepSea (DSE7320)
Operating temperature: -20°C~60°C
Relative Humidity: 95%
Operating voltage: DC24V (range: 18-30V, pressure: 50V/5 mm )
Standard functions: Engine Control/Generator Monitoring/Generator Protection/
Engine Monitoring/Clear Text Display
Shutdown: Loss of Speed Signal,Alternator Under / Over Voltage,Alternator Under/ Over Frequency,
Mains Under / Over Voltage,Mains Under/ Over Frequency,Under / Over Speed,Low Oil Pressure,High Engine Temperature,Phase Sequence Electrical (Option),Earth Fault (Option)
Warning: Alternator Under / Over Voltage,Alternator Under/ Over Frequency,Mains Under / Over Voltage,Mains Under/ Over Frequency,Under / Over Speed,Low Oil Pressure Pre-Alarm,High Engine Temperature Pre-Alarm,High/Low Battery Voltage,Over-current,Periodic maintenance
