18kW High Quality Single Phase Diesel Generator Details

18kW High Quality Single Phase Diesel Generator Details photo-1
US$ 2,200 - 6,700 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
Shanhua
Model Number:
HL18GF
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shanghai, China
Brand Name Shanhua
Model Number HL18GF
Output Type AC Three Phase
Speed 1500RPM
Frequency 50HZ
Rated Power 18KW/22.5KVA
Rated Voltage 110/220V
Rated Current 32.4A

Specifications

- 18kW High Quality Single phase diesel generator Details
- 100% copper wire
- Open/silent generator
- Promptly delivery



18kW yangdong High Quality Single phase diesel generator Details



Genset :

Model: HL18GF

Prime Power (KVA / KW): 22.5/18

Standby Power (KVA / KW): 24.75/19.8

Rated Ammeter (A): 32.4

Dimensions (mm) (L×W×H): 1400 ×850 ×1125

Net Weight (kg):460



18kW High Quality Single phase diesel generator Details



 Engine:

Manufacturer: Yangdong

Model: YSD490D

Number of cylinders: 4

Aspiration: Turbo

Bore×Store(mm): 90× 100

Compression ratio: 18:1

Displacement, total (L): 2.54

Speed Governor: Mechanical

Cooling System:  Water Cooled

Fuel Consumption at 100% Load (g/kw. h): 247.5

Starting Method: 24V DC Starter



Alternator:

STAMFORD,MARATHON, SHANHUA, 3 Phase and 4 Wires, 100% copper wire Brushless, Self-exciting, IP21-IP23, and Insulation Class:  H



18kW High Quality Single phase diesel generator Details

Products Exhibition :





18kW High Quality Single phase diesel generator Details

18kW High Quality Single phase diesel generator Details



18kW High Quality Single phase diesel generator Details

18kW High Quality Single phase diesel generator Details



Production Line :



18kW High Quality Single phase diesel generator Details18kW High Quality Single phase diesel generator Details



 Test Center:



18kW High Quality Single phase diesel generator Details



 The items been tested on the diesel generators are mainly as follows:



1) Each diesel generator is tested more than 4 hours totally. They are tested on idle load, load, fully load and 10% overload.



2) The noise level is tested.



3) Operation of the various meters on the control panel is tested.



4) The diesel generator appearance and all marks are checked as well.



Packing Type :



 18kW High Quality Single phase diesel generator Details18kW High Quality Single phase diesel generator Details



Cooperations:



18kW High Quality Single phase diesel generator Details

18kW High Quality Single phase diesel generator Details







 Contact Us :



18kW High Quality Single phase diesel generator Details
