Specifications
- 120kva domestic diesel generator sale- Yuchai OEM factory
- 100% copper wire
- Factory supply
Shandong Huali Electromechanical Co.,LTD
120kva domestic diesel generator sale
Specification of genset
Genset model:HL120GF
Prime power: 96KW/120KVA
Standby power: 105.6KW/132KVA
Power factor: 0.8
Rated Voltage: 400/230V
Rated frequency (HZ): 50
Dimensions (mm) (L×W×H): 2340×800×1320
Weight (kg): 1350
Specification of diesel engine
Engine Model: YC6B108L-D20
Manufacturer: YUCHAI
Governor: M/E
Air intake way: NA
Cylinders/Arrangement: 6/L
Bore× Stroke(MM): 108×115
Fuel Consumption Rate(L/h): 200
Lubricating oil capacity(L): 17
Coolant capacity (L): NA
Compression ratio: 17.5:1
Displacement, total (L): 6.87
Net weight (kg): 370
Engine speed (rpm): 1500
Max Power (kW): 132
Starting Method: DC12V electrical starting
Specification of alternator
Alternator model: HLF120
Connecting Type: 3 Phase and 4 Wires
Number of Bearing: 1
Protection Grade: IP21
Altitude: ≤1000m
Exciter Type: Brushless, Self-exciting, AVR automatic voltage regulating,100% Copper winding wire
Insulation Class: H
Telephone Influence Factor (TIF):≤50
Voltage Regulation, Steady State: ≤±1%
Transient State Voltage: ≤-15%~+20%
Control System
Operating temperature: -20°C~60°C
Relative Humidity: 95%
Operating voltage: DC24V (range: 18-30V, pressure: 50V/5 mm )
Standard functions: Engine Control/Generator Monitoring/Generator Protection/
Engine Monitoring/Clear Text Display
Shutdown: Loss of Speed Signal,Alternator Under / Over Voltage,Alternator Under/ Over Frequency,
Mains Under / Over Voltage,Mains Under/ Over Frequency,Under / Over Speed,Low Oil Pressure,High Engine Temperature,Phase Sequence Electrical (Option),Earth Fault (Option)
Warning: Alternator Under / Over Voltage,Alternator Under/ Over Frequency,Mains Under / Over Voltage,Mains Under/ Over Frequency,Under / Over Speed,Low Oil Pressure Pre-Alarm,High Engine Temperature Pre-Alarm,High/Low Battery Voltage,Over-current,Periodic maintenance
Products Exhibition :
Production Line :
2000KW Cummins electric power generator set installation case:
Certificates :
Office :
Contact Us :
Send Inquiry to This Supplier
