4-20MA Stainless Steel Pneumatic Single Acting Segment Regulating Ball Valve
US$ 1 - 500
MOQ: 1 Piece
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Ball
Pressure:
Low Pressure
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Nongbi Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Flange End Water Steam Pneumatic Regulating ValveUS$ 1 - 500MOQ: 1 Piece -
SUS316 Flange End Water Steam Pneumatic Steam Cutting O-Type Ball ValveUS$ 1 - 500MOQ: 1 Piece
-
Gear Type Pneumatic Actuating O-Type Cutting Ball ValveUS$ 1 - 500MOQ: 1 Piece
-
Pneumatic Knife Gate Valve Pneumatic Slurry Valves Parallel Slide ValvesUS$ 1 - 500MOQ: 1 Piece
-
Pneumatic Stainless Steel Knife Gate ValveUS$ 1 - 500MOQ: 1 Piece
Standard or Nonstandard
Standard
Structure
Ball
Pressure
Low Pressure
Power
Pneumatic
Material
Stainless Steel
Temperature of Media
High Temperature
Media
Gas
Port Size
DN10-DN500
Place of Origin
Zhejiang, China
Model Number
PSSV-TST100
Brand Name
Lageci
Application
General
|
|
4-20MA Stainless Steel Pneumatic Single Acting Segment Regulating Ball valve
Nominal Pressure Rating:1.6 Mpa, 2.5 Mpa, 4.0Mpa Working Temperature:-20~300℃ Nominal Diameter:DN10-500mm Rated Flow Coefficient:18~19290Kv Main Material:Valve Body 304,316,316L Valve Plug 304,316,316L input Signal:4-20mADC Seal Type: Self-adjusting Stainless Steel Hard Seal(Soft Seal) Leakage:GB/T4213-2008IV Actuator Type:Single Acting(Spring return) Air Supply Pressure:0.4-0.6Mpa Accessories:1.Positioner 2.Air Filter+Regulator 3.Flange
|
|
|
|
|
|
|
|
|
|
|
|
