DN80-1600(mm) Socket-spigot Fittings Ductile Iron Pipe Fitting

DN80-1600(mm) Socket-spigot Fittings Ductile Iron Pipe Fitting thumbnail-1
DN80-1600(mm) Socket-spigot Fittings Ductile Iron Pipe Fitting thumbnail-2
DN80-1600(mm) Socket-spigot Fittings Ductile Iron Pipe Fitting thumbnail-3
DN80-1600(mm) Socket-spigot Fittings Ductile Iron Pipe Fitting thumbnail-4
DN80-1600(mm) Socket-spigot Fittings Ductile Iron Pipe Fitting thumbnail-5
DN80-1600(mm) Socket-spigot Fittings Ductile Iron Pipe Fitting thumbnail-6
DN80-1600(mm) Socket-spigot Fittings Ductile Iron Pipe Fitting photo-1
DN80-1600(mm) Socket-spigot Fittings Ductile Iron Pipe Fitting photo-2
DN80-1600(mm) Socket-spigot Fittings Ductile Iron Pipe Fitting photo-3
DN80-1600(mm) Socket-spigot Fittings Ductile Iron Pipe Fitting photo-4
DN80-1600(mm) Socket-spigot Fittings Ductile Iron Pipe Fitting photo-5
DN80-1600(mm) Socket-spigot Fittings Ductile Iron Pipe Fitting photo-6
US$ 900 - 1,020 MOQ: 20 Pieces
Key Specifications
Get Latest Price
Material:
Iron
Technics:
Casting
Type:
Flange
Contact Supplier Request Quote Chat Now
Tianjin Dunhui Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin; Qingdao; Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Material Iron
Technics Casting
Type Flange
Place of Origin Tianjin, China
Model Number ductile iron pipe
Brand Name DUNHUI
Connection Other, push on
Shape Reducing
Head Code Other, circle, Round

Ductile iron pipe fitting



DUNHUI is specialized in producing a full range of ductile iron pipe fittings, and Construction Products. Including the following aspects:



·Flanged pipe fittings as per EN545/ISO2531

·Loosing flange fitting

·Ductile iron push-in socket pipe fitting

·Mechanical Joint socket pipe fittings(MJ)

·Express Joint socket pipe fittings(EX)

·Fittings for PVC pipes

·AWWA C110 Flanged Fittings

·AWWA C153 MJ Fittings

·Other pipeline Accessories and according to customers’ drawing



 “DUNHUI” is your correct choice. Welcome to visit



1.    DN80-1600(mm)  socket-spigot fittings ductile iron pipe fitting



DN80-1600(mm) socket-spigot fittings ductile iron pipe fitting



DN80-1600(mm) socket-spigot fittings ductile iron pipe fitting



DN80-1600(mm) socket-spigot fittings ductile iron pipe fitting



DN80-1600(mm) socket-spigot fittings ductile iron pipe fitting



DN80-1600(mm) socket-spigot fittings ductile iron pipe fitting



DN80-1600(mm) socket-spigot fittings ductile iron pipe fitting

Made of ductile iron.

Blue epoxy painted finish.
According to UNE-EN 545 norms.
Same body dimensions for PN10, PN16 andPN25.





2.  Products description and Main dimensions



Material

Ductile iron, grade 500-7/450-12 in accordance with ISO10083

Gasket

 Rubber EPDM in accordance with EN681.1

Pressure

  PN10, PN16 andPN25

Fluid Temperature

0°C-50°C, excluding frost

Internal lining

 Fusion bonded epoxy

External Coating

Epoxy applied by FBE

Reference rules

Dimensions and testing in accordance with EN545

Usage

 Connected by flange





Nominal Size and Weight of Socket-spigot Bend 90°(1/4)
DN/mm e/mm Lu Lu′ weight(Kg)
80 7 100 280 10.1
100 7.2 120 300 13.3
125 7.5 145 325 15.5
150 7.8 170 350 24
200 8.4 220 400 38.3
250 9 270 450 60.6
300 9.6 320 500 78
350 10.2 370 550 112
400 10.8 420 600 146
450 11.4 470 670 165
500 12 520 720 230
600 13.2 620 820 337
700 14.4 720 900 490
800 15.6 820 1000 665
900 16.8 920 1100 880
1000 18 1020 1200 1137
1100 19.2 1120 1300 1190
1200 20.4 1220 1400 1574
1400 22.8 1220 1400 2018
1500 24 1270 1525 2196
1600 25.2 1290 1555 2605







 3. Production process





Quality Control Groups



  • Dimensions Test
  • Manufacture process Inspection
  • Process Inspection including sand cleaning, assembling, packing and coating
  • Final Inspection including delivery marks and etc.
  • Particular Tests for different products, such as Load Test, Hydro Test and etc.
      Process
DN80-1600(mm) socket-spigot fittings ductile iron pipe fitting


Raw Material Inspection



  • Raw Material inspection including chemical
  • components analysis, tensile strength test and etc.

Laboratory



  • Chemical Components
  • Microstructure Test
  • Tensile Strength


4.  Ductile iron pipe fitting pictures

DN80-1600(mm) socket-spigot fittings ductile iron pipe fitting

   DN80-1600(mm) socket-spigot fittings ductile iron pipe fitting




5. Technical Standard:



 Design: EN545
 Certification: ISO9001:2008





6. Personnel station:



  Have professional salesmen, and 6 Engineers, More than 30 inspectors.





 7. Quality and Safety:



We have a very strict and complete quality control system, which promises that goods we produced are always of the best quality, the enough inspectors to ensure that each product can meet the quality requirements of customers. We do the final inspection in own factory with ISO 9001:2008.





8.Location:



 DUNHUI has a convenient location at the city’s exporting business zone, Dongli District. We are only 9 km to Tianjin  International Airport, and very close to major highways,TIANJIN port. We look forward to work with your business!



DN80-1600(mm) socket-spigot fittings ductile iron pipe fitting
