50kva Three Phase Generator Diesel Generator Powered by Cummins Engine

FOB Price

US$ 1,500 - 2,500 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

high quality customized kinds of diesel generator diesel genset ,diesel engine supplier weifang shandong china supplier

40kw Diesel Generator
1. Specification of genset
Gensets model	HUAKE40
Prime power	40KW/50KVA
Rated Voltage(V)	400/230
Rated frequency(HZ)	50
Rated Speed(RPM)	1500
Power Factor	0.8(lagging)
Dimensions(mm) (L×W×H)	1680x600x1310	Open type
Genset Weight(kg)	1000
Dimensions(mm) (L×W×H)	2400x1000x1560	Silent type
Genset Weight(kg)	1500
2. Specification of diesel engine
Engine model	HUAKE40
Standby Power	50 kW/62.5 kVA
Number of Cylinders	3
Cylinder arrangement	In-line
Cycle	Four stroke
Aspiration	Turbo
Bore×Stroke (mm×mm)	105 x 120
Displacement (Liter)	3.1
Compression Ratio	16.5:1
Speed Governor	Mechanical
Cooling System	Forced Water Cooling Cycle
Total lubrication system capacity (L)	7.25
Fuel Consumption at 100% Load (g/kw.h)	208
Starting Method	DC24V electrical starting
3. Specification of alternator
Alternator brand	Stamford
Alternator model	UCI 224D
Rated power	40KW/50KVA
Number of Phase	3
Connecting Type	3 Phase and 4 Wires
Number of Bearing	1
Protection Grade	IP23
Altitude	≤1000m
Exciter Type	Brushless ,Self-exciting, AVR automatic voltage regulating,100% Copper winding wire
Insulation Class	H
Telephone Influence Factor (TIF)	≤50
THF	≤2%
Voltage Regulation, Steady State	≤±1%
Transient State Voltage	≤-15%~+20%

Why choose us

1.The quality is assured.

2.We are manufacturer not trading company.

3.Sample will be offered before placing order if you need.

3.Our factory is near by Qingdao port,so it is convenience for delivery.

4.We have good after-sale service.
