400kw 480kw 500kw 600kw 720kw 800kw 900kw 1000kw 1100kw 1200kw 50Hz Silent Power Diesel Generator Set

400kw 480kw 500kw 600kw 720kw 800kw 900kw 1000kw 1100kw 1200kw 50Hz Silent Power Diesel Generator Set thumbnail-1
400kw 480kw 500kw 600kw 720kw 800kw 900kw 1000kw 1100kw 1200kw 50Hz Silent Power Diesel Generator Set thumbnail-2
400kw 480kw 500kw 600kw 720kw 800kw 900kw 1000kw 1100kw 1200kw 50Hz Silent Power Diesel Generator Set thumbnail-3
400kw 480kw 500kw 600kw 720kw 800kw 900kw 1000kw 1100kw 1200kw 50Hz Silent Power Diesel Generator Set photo-1
400kw 480kw 500kw 600kw 720kw 800kw 900kw 1000kw 1100kw 1200kw 50Hz Silent Power Diesel Generator Set photo-2
400kw 480kw 500kw 600kw 720kw 800kw 900kw 1000kw 1100kw 1200kw 50Hz Silent Power Diesel Generator Set photo-3
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Self-Starting Diesel Generator
Stroke:
Four Stroke
Usage:
Common Units
Contact Supplier Request Quote Chat Now
Fuzhou Sinostar Power Co.,ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
FUZHOU
Delivery Detail:
25 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Self-Starting Diesel Generator
Stroke Four Stroke
Usage Common Units
Speed Speed
Cooling Method Water Cooling
Installation Method Fixed
Excitation Mode AC Rotating Exciter
Conditions of Use Land Use
Landuse Type of Unit Low Noise
Output Type AC Three Phase
Transport Package PLYWOOD CASE
Origin CHINA

400kw 480kw 500kw 600kw 720kw 800kw 900kw 1000kw 1100kw 1200kw
50Hz Silent Power Diesel Generator Set

1.PRODUCT Feature
power output:20KW~1380KW
Powered by water-cooled diesel engine
Alternator:Stanford,Leroy somer,Marathon,
AMF panel with ATS
Soundproof,weather proof,trailer type for optional
Manual of engine,alternator and control system
 with two storage battery and silencer
 Fuel tank for 8 H running based on frame
1 year or  1000 H guarantee

2.Technical specifications( 20KW~1380KW )

SPECIFICATION SHEET FOR 50HZ GENERATOR SETS
(1500 rpm, 3-phase 4-wire, 230/400V, PF=0.8)
Generator Set Model Prime Power Standby Power Engine Maximum current(A)
Prime Standby KW KVA KW KVA MODEL  Power (kw)
SP-C20P-1 SP-C22S-1 20 20 22 22 4B3.9-G1 24-27 96
SP-C20P-1 SP-C22S-1 20 20 22 22 4B3.9-G2 24-27 96
SP-C25P SP-C28S 20 25 22 27.5 4B3.9-G1 24-27 40
SP-C28P SP-C30S 22 27.5 24 30 4B3.9-G2 24-27 43
SP-C40P SP-C44S 32 40 35 44 4BT3.9-G1 36-40 64
SP-C40P SP-C44S 32 40 35 44 4BT3.9-G2 36-40 64
SP-C43P SP-C48S 34 42.5 40 50 4BTA3.9-G2 50-55 72
SP-C50P SP-C55S 40 50 44 55 4BTA3.9-G2 50-55 79
SP-C56P SP-C62S 45 56 50 62 4BTA3.9-G2 50-55 89
SP-C60P SP-C65S 48 60 52 65 4BTA3.9-G2(QC58) 58-64 94
SP-C65P SP-C70S 52 65 56 70 4BTA3.9-G2(QC58) 58-64 101
SP-C73P SP-C80S 58 72.5 64 80 4BTA3.9-G11 70-80 115
SP-C80P SP-C85S 64 80 68 85 4BTA3.9-G11 70-80 123
SP-C85P SP-C93S 68 85 74 92.5 4BTA3.9-G13 87-97 134
SP-C85P SP-C93S 68 85 74 92.5 6BT5.9-G1 86-92 134
SP-C95P SP-C105S 76 95 84 105 4BTA3.9-G13 87-97 152
SP-C94P SP-C100S 75 94 80 100 6BT5.9-G1 86-92 144
SP-C100P N.A 80 100 N.A N.A 4BTA3.9-G13 87-97 144
SP-C100P N.A 80 100 N.A N.A 6BT5.9-G2 86-92 144
SP-C100P SP-C110S 80 100 88 110 4BTAA3.9-G3 96-106 159
SP-C100P SP-C110S 80 100 88 110 6BT5.9-G2(QC96) 96-106 159
SP-C115P SP-C125S 92 115 100 125 6BTA5.9-G2 106-116 180
SP-C135P SP-C143S 108 135 116 145 6BTAA5.9-G2 120-130 209
SP-C155P SP-C170S 124 155 136 170 6BTAA5.9-G12 140-155 245
SP-C180P SP-C200S 145 180 160 200 6CTA8.3-G1 163-180 289
SP-C180P SP-C200S 145 180 160 200 6CTA8.3-G2 163-180 289
SP-C200P SP-C215S 160 200 172 215 6CTAA8.3-G2 183-203 310
N.A. SP-C250S N.A. N.A. 200 250 6CTAA8.3-G9 361
SP-C225P SP-C250S 180 225 200 250 6LTAA8.9-G2 220-240 361
SP-C250P SP-C275S 200 250 220 275 6LTAA8.9-G3 230-250 397
SP-C275P SP-C313S 220 275 250 313 6LTAA9.5-G3 250-280 452
SP-C313P SP-C350S 250 312.5 280 350 6LTAA9.5-G1 290-320 505
SP-C350P SP-C390S 280 350 310 390 6ZTAA13-G3 340-380 563
SP-C375P SP-C413S 300 375 330 413 6ZTAA13-G3 340-380 596
SP-C388P SP-C425S 310 388 340 425 6ZTAA13-G3 340-380 613
SP-C400P SP-C438S 320 400 350 437.5 6ZTAA13-G2 390-415 631
SP-C425P SP-C475S 340 425 380 475 6ZTAA13-G2 390-415 686
SP-C438P SP-C475S 350 438 380 475 6ZTAA13-G4 400-415 686
SP-C438P SP-C475S 350 438 380 475 QSZ13-G2 400-440 686
SP-C450P SP-C500S 360 450 400 500 QSZ13-G5 411-470 722
SP-C475P SP-C500S 380 475 400 500 QSZ13-G3 450-470 722
SP-C500P SP-C550S 400 500 440 550 QSZ13-G10 463-509 794
SP-C250P SP-C275S 200 250 220 275 NT855-GA 231-254 397
SP-C250P SP-C275S 200 250 220 275 MTA11-G2 224-246 397
SP-C250P SP-C275S 200 250 220 275 NTA855-G1 240-264 397
SP-C250P SP-C275S 200 250 220 275 QSNT-G6 243-265 397
SP-C275P SP-C313S 220 275 250 313 QSNT-G7 261-291 452
SP-C275P SP-C313S 220 275 250 313 NTA855-G1A 261-291 452
SP-C313P SP-C340S 250 313 272 340 MTAA11-G3 282-310 491
SP-C313P SP-C350S 250 313 280 350 NTA855-G1B 283-321 505
SP-C313P SP-C350S 250 313 280 350 QSNT-G1 291-325 505
SP-C345P SP-C375S 275 345 300 375 NTA855-G2A 313-343 541
SP-C350P SP-C390S 280 350 310 390 NTA855-G4 313-343 563
SP-C350P SP-C390S 280 350 310 390 QSNT-G2 321-358 563
SP-C375P SP-C400S 300 375 320 400 NTAA855-G7 343-377 577
SP-C400P SP-C438S 320 400 350 437.5 QSNT-G3 358-392 631
N.A. SP-C450S N.A. N.A. 360 450 NTAA855-G7A 650
SP-C375P SP-C412S 300 375 330 412 KTA19-G2 336-369 595
SP-C450P SP-C500S 360 450 400 500 QSNT-G4X 407-448 722
SP-C450P SP-C500S 360 450 400 500 KTA19-G3 403-448 722
SP-C450P SP-C500S 360 450 400 500 QSK19-G14 402-447 722
SP-C500P SP-C550S 400 500 440 550 KTA19-G3A 448-504 794
SP-C500P SP-C550S 400 500 440 550 KTA19-G4 448-504 794
SP-C500P SP-C550S 400 500 440 550 QSK19-G13 451-501 794
SP-C525P SP-C600S 420 525 480 600 KTAA19-G5 470-555 866
N.A. SP-C650S N.A. N.A. 520 650 KTA19-G8 938
SP-C575P SP-C650S 460 575 520 650 KTAA19-G6 520-570 938
SP-C575P SP-C630S 460 575 504 630 QSK19-G12 503-565 909
SP-C588P SP-C650S 470 588 520 650 QSK19-G6 520-592 938
SP-C600P SP-C650S 480 600 520 650 KTAA19-G6A 938
N.A. SP-C687S N.A. N.A. 550 687 KTAA19-G6A 992
N.A. SP-C687S N.A. N.A. 550 687 KTAA19-G7 992
SP-C650P SP-C700S 520 650 560 700 QSK19-G4 574-634 1010
SP-C660P SP-C725S 528 660 580 725 QSK19-G11 606-667 1046
SP-C660P SP-C725S 528 660 580 725 QSK19-G11X 606-667 1046
SP-C625P SP-C700S 500 625 560 700 KT38-G 560-615 1010
SP-C712P SP-C787S 570 712 630 787 KTA38-G1 634-701 1136
SP-C725P SP-C800S 580 725 640 800 KT38-GA 647-711 1155
SP-C750P SP-C825S 600 750 660 825 KTA38-G2 664-731 1191
SP-C750P SP-C825S 600 750 660 825 QSK38-G8 657-730 1191
SP-C800P SP-C880S 640 800 704 880 KTA38-G2B 711-789 1270
SP-C800P SP-C880S 640 800 704 880 QSK38-G7 705-783 1270
SP-C910P SP-C1000S 728 910 800 1000 KTA38-G2A 813-895 1443
SP-C910P SP-C1000S 728 910 800 1000 QSK38-G6 791-878 1443
SP-C940P SP-C1025S 752 940 820 1025 KTA38-G5 880-970 1480
SP-C1000P SP-C1100S 800 1000 880 1100 KTA38-G5 880-970 1588
SP-C1000P SP-C1100S 800 1000 880 1100 QSK38-G1 876-970 1588
N.A. SP-C1250S N.A. N.A. 1000 1250 KTA38-G9 1804
SP-C1135P SP-C1250S 908 1135 1000 1250 QSK38-G2 989-1096 1804
SP-C1250P SP-C1375S 1000 1250 1100 1375 QSK38-G5 1107-1224 1985
SP-C1250P SP-C1375S 1000 1250 1100 1375 KTA50-G3 1097-1227 1985
SP-C1375P SP-C1600S 1100 1375 1280 1600 KTA50-G8 1200-1429 2309
SP-C1375P SP-C1500S 1100 1375 1200 1500 QSK38-G19 1212-1334 2165
SP-C1475P SP-C1600S 1180 1475 1280 1600 KTA50-GS8 1287-1429 2309
SP-C1650P SP-C1800S 1320 1650 1440 1800 KTA50-G15 1491-1656 2598


Sale promise:
SINOSTAR Power provides a full line of brand new and high quality products. Each and every unit is strictly Factory tested.
Warranty is according to our standard conditions:
a, 15 months, counted on the day SINOSTAR sold to the first buyer;
b, One year after installation;
c, 1000 running hours (accumulated); subject to the earlier one.
Service and parts are available from SINOSTAR Power or distributors in your location.
