Specifications
1. ISO9001 Certificated.2. Factory direct price.
3. Original Packing.
4. Wide application.
5. Different model.
LMI Milton Roy is the leading manufacturer of Chemical Metering Pumps, Controllers, and accessories.
Introducing the ROYTRONIC Series A metering pump offering a robust design, control options and improved electro-magnetics to meet all flow / pressure ratings. The pumps are available for applications up to 250 psi with capacities between .001 and 2.0 GPH. Single or dual manual control options with pulse input or 4-20 mA input are available. The line includes ferrule designed fittings that set a new standard for secure, leak-proof tubing connections.
Series B and C Chemical Metering Pumps
Series B and C Chemical Metering Pumps have been an industry standard for over 20 years. The familiar yellow and black pumps have a rugged, totally enclosed, chemically resistant housing for protection in the harshest environments. Encapsulated electronics and a rigid housing and stroke bracket ensure years of precise, repeatable performance. Several control options are available for all applications and budgets:
Type “9” control is designed for easy integration into chemical feed systems. The stroke rate may be controlled manually or by an external signal generated by a flowmeter, controller, transmitter, PLC or other device. Divide or multiply a digital (pulse) input or program a response to a milliamp (4-20, 0-20, 20-4, 20-0) input. Remote on/off and low level inputs are standard. The clear liquid crystal display provides the user with operational status. The unique 5-level power control reduces system shock and extends the life of the pump. The optional Digi-Pulse Flow Monitor verifies chemical flow and provides an alarm output.
Type “7” control is designed for more economical systems. The stroke rate may be controlled manually or by a digital input. The optional Micropace Control Modules enable the user to divide or multiply a digital input or respond directly and proportionally to a 4 - 20 milliamp input. A low level input is standard.
Type “1” control is designed for accurate chemical feed where manual or on/off control is all that is required. Dual manual control of stroke speed and stroke length are provided.
Series G Motor-Driven Metering Pumps
The Series G Metering Pump is designed for high output applications. The drive incorporates a variable eccentic design which ensures smooth output and reduces system shock. The mechanically actuated diaphragm reduces the possibility of hydraulic oil contamination of process liquid which makes this an ideal pump for water treatment applications. DC variable speed drives are available for external control and automation.
The SD & SG metering pumps offer a high level of reliability with outstanding value for applications up to 175 psi (12 Bar).
