Plastic pellets automatic loader with good quality

FOB Price

US$ 500 - 800 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	plastic loader
Place of Origin	Guangdong, China	Brand Name	Longhe
Model Number	AS-300G	Voltage	220V, according to customer
Power(W)	950W	Dimension(LWH)	400x360x660mm
Weight	11kg	Certification	ISO9001 and CE
Warranty	One year	After-sales Service Provided	Engineers available to service machinery overseas

Application and praperties:

1,Application to conveying nonstick powder and poeder mixture,including resin powder,bakelite powder and paints;

2,Eliminating dust flying during the transfer,realizing dust-free operation in workshop;

3,High-pressure air injection to shatter dust instantly,ensuring smooth powder suction;

4,Stainless steel hopper ensuring no material pollution,easy to clean;

5,Microcomputer touch-type control,easy and simple to operate.

TECHNICAL PARAMETERS:

Model			AS-300G	AS-400G	AS-800G	AS-800G2	AS-900G
Motor power(w)	Type		Carbon Brush Type	Induction Type	Induction Type	Induction Type	Induction Type
Motor power(w)	Specification		950	750	750	1100	3000
Voltage Specification			1Φ,220v,50HZ	3Φ,380v,50HZ	3Φ,380v,50HZ	3Φ,380v,50HZ	3Φ,380v,50HZ
Material Feeding Capacity(kg/h)			300	400	400	550	600
Suction Lift(M)			4	4	4	4	4
Static Air Pressure(MAX)			1500mm/HZO	1800mm/HZO	1800mm/HZO	1800mm/HZO	3000mm/HZO
Storage Tank Capacity(L)			6	10	7.5	7.5	10
Internal Diameter of Conveying Pipe(mm)			Φ38	Φ38	Φ38	Φ38	Φ38
Overall Diamension(mm)		Hopper	/	/	460x380x550	460x380x550	460x380x700
Overall Diamension(mm)		Main Unit	400x360x600	400x300x500	400x300x440	400x300x440	500x400x600
Weight(kg)			11	28	55	65	85
