NEW DESIGN Remote eye TV Link system
- 100000 Piece / Pieces per Month
- shanghai/Ningbo
- T/T Credit Card
- TAIYITO video intercom smarthome Intelligent Home Digital Indoor Gateway(7")
- TYT smarthome gateway / home applainces remote comtroller in zigbee coordinator system
- 2015 popular smart home automation remote controler for home appliances
- TAIYITO High quality colorful touch screen switch for smart home automation system
- TAIYITO zigbee smart home kit domotic buildings automation in housing estate
- TYT app remote control smart home automation
Product Details
Brand Name: | ROGETECH | Model Number: | Remote eye | Use: | TV |
Place of Origin: | Zhejiang, China |
Product Description
Specifications
1.Connect all of the Sky digital receiver (Digibox) come up with a second output.2.Remote control distance : more than 5m
Introduction
*professional remote eye are designed to be used with SKY digi-boxes and SKY+ receives ;
*professional remote eye are designed to allow viewers watching SKY digital satellite programmes on a second TV away from the digital receiver .
*Viewers could operate their sky digibox using a remote control from another point in their house - bedroom, kitchen etc.
*You simply run a coax cable (not supplied) from the socket marked RF2 on the back of your digibox to your other TV to provide the pictures, fit the Sky TV Link onto this lead and you will be able to control your digibox from this point.
|
Master set up:
|
Installing the Remote eye:
1.Connect the short lead with the male plug which is attached to the R6536 link to the aerial input socket on the second TV. 2. Connect the male plug on the length of coaxial cable to the female socket on the R6536. 3.Position the R6536 infrared eye in the clear line of sight from where you will be using the remote control ( for example: on the top of TV set , same as the pic.)
|
Main Technical Specifications:
Frequency Range : 47--862MHz
All port F-(f) connector,75 ohm.
Number of input : 1
Number of output : 1
Insertion loss: ≤2dB
Carrier frequency: 6.5MHz±0.5MHz
Remote operation ≥5m
Power supply: 9Vdc/15mA
|
