Hot Sale Video Balun for CCTV System Surge Protection ESD Anti-jammingYJS-213AVP

Hot Sale Video Balun for CCTV System Surge Protection ESD Anti-jammingYJS-213AVP photo-1
Hot Sale Video Balun for CCTV System Surge Protection ESD Anti-jammingYJS-213AVP photo-2
Hot Sale Video Balun for CCTV System Surge Protection ESD Anti-jammingYJS-213AVP photo-3
Hot Sale Video Balun for CCTV System Surge Protection ESD Anti-jammingYJS-213AVP photo-4
Hot Sale Video Balun for CCTV System Surge Protection ESD Anti-jammingYJS-213AVP photo-5
Negotiable MOQ: 100 Pairs (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Winkasing
Model Number:
YJS-213AVP
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name Winkasing
Model Number YJS-213AVP

Hot Sale Video Balun for CCTV System  Surge Protection ESD Anti-jamming

YJS-213AVP

Features:

  • NTSC,PAL&SECAM video format compatible
  • Real time transmission
  • Exceptional interference rejection
  • Wave Filter Design,Anti-Static Design,Surge Protection
  • Long-distance transmission and high-quality image
  • Compact size and easy installation
  • Cost-effective

Product Description
ITEMSSPECIFICATION
Transmission Distance
Transmission Distance with passive300-450m
Video
Video FormatPAL,NTSC,SECAM
Operating FrequencyDC to 6MHz
Common-mode/Different-mode rejection15KHz to 5MHz   60 dB typ
Attenuation1.5dB typ Max
ImpedanceMale BNC:75Ω
Terminal block:100Ω
Wire type
Category Type5 or better
Impedance100±20ohms
DC Loop Resistance52 ohms per 1000ft(18 ohms per 100m)
DC Loop ResistanceDifferent Capacitance
Power
No External power requiredNo External power required
Protection
Surge ProtectionRenewable solid state surge protection
Video Input2KV(common mode),10/700us IEC6100-4-5/1995(GB/T 1726,5-1999)
Video Output2KV(common mode),10/700us IEC6100-4-5/1995(GB/T 1726,5-1999)
Connector
Video input/outputMale BNC / DC Jack/RJ45
Mechanical
HousingABS engineering plastic
Body ColorGray
Dimensions146*103*28mm
Gross weight65g
Environment
Operating Temperature-20℃-70℃
Relative Humidity0-95%(non-condensing)
Storage Temperature-40℃-80℃




Hot Sale Video Balun for CCTV System Surge Protection ESD Anti-jammingYJS-213AVPHot Sale Video Balun for CCTV System Surge Protection ESD Anti-jammingYJS-213AVP

Hot Sale Video Balun for CCTV System Surge Protection ESD Anti-jammingYJS-213AVP





Our Services

1. We guarantee that all our items are "as stated" in their descriptions. We strive for 100% customer satisfaction on every sale we complete.
2. Your satisfaction and positive feedback is very important to us. Please leave positive feedback and 5 stars if you are satisfied with our items and services.
3. If you have any problems with our items or services, please feel free to contact us first before you leave negative feedback. We will do our best to solve any problems and provide you with the best customer services.

Product Performance

Hot Sale Video Balun for CCTV System Surge Protection ESD Anti-jammingYJS-213AVP



The function of the CCTV Video Balun  is to allow the traditional 75-ohm coaxial video cable to be replaced by Category 5E/6 (or better) twisted pair in the CCTV security and surveillance environment, thereby allowing CCTV camera and monitoring equipment to be deployed more cost-effectively using structured cabling techniques.
