Specifications:
This product is widely applied to industries and fields that need aloft work such as stations,docks,and public construction.It is characterized by convenient mobility,simple only supports with four legs but also with only one leg.It is easy for operation.
About the products
The products are insured for liabilities by Peoples insurance Company of China.
The products are equipped with safety and anti-explosion devices for hydraulic pipelines
The products are equipped with earth leakage protection devices.
Elevating mechanism adopts high-strength manganese steel rectangular pipe.
Safety device to prevent the elevating platform from overloading.
Emergency falling device in case of power out.
Technology parameters:
| Model | Max operating height(m) | Max operating radius(m) | Rotating angle | Max overall dimension L*W*H(mm) | Platform load(kg) | Overall weight(kg) | Elevatingspeed(m/s) | Operating pressure(mpa) | Working speed(km/h) | Windresistance |
| SJYZ0.16-8 | 8 | 3.4 | 360° | 3400*1950*2700 | 160 | 1700 | 0.05-0.09 | 10 | 15-30 | ≤5 |
SJYZ0.16-10 |
10 | 3.4 | 360° | 3400*1950*2800 | 160 | 1800 | 0.05-0.09 | 10 | 15-30 | ≤5 |
| SJYZ0.16-12 | 12 | 3.4 | 360° | 3400*1950*2950 | 160 | 1900 | 0.05-0.09 | 10 | 15-30 | ≤5 |
