Specifications
Full hydraulic drive , easy operation and reliable running .Adopted anti-slip checked steel plate to guarantee
product characteristics
1.Full hydraulic drive , easy operation and reliable running
2.Labrum and platform adopt integrated long shaft for connection , producing high strength and reliability .
3.Imported seal, ensure the hydraulic system has good sealing performance.
4.Imported hydraulic pressure station module type whole, good sealing, long service life.
5.High strength "U" shape beam design can safeguard the high load long time running deformation.
6.The slippery decorative pattern plate, is with good performance of the platform slippery.
7.With security maintenance workers into the cllimbing when maintaining safety of internal support staff.
Mobile ramp technology parameters
| Model |
Rated load (kg) |
Amplitude range (mm) |
Length (mm) |
width (mm) |
Wheel space (mm) |
Full range handing times |
Overall weight (kg) |
| DCQY6-0.9 | 6000 | 900 | 10500 | 2000 | 1500 | 50 | 2300 |
| DCQY8-0.9 | 8000 | 900 | 10500 | 2000 | 1500 | 50 | 2900 |
| DCQY10-0.9 | 10000 | 900 | 10500 | 2000 | 1500 | 50 | 3100 |
About the products
1. The products are insured for liabilities by People's insurance company of china
2.The products are equipped with safety and anti-explosion device
3.The products are equipped with earth leakage protection devices .
4.Elevating mechanism adopts high-strength manganese steel rectangular .
5.Safety device to prevent the elevating platform from overloading .
6.Emergency falling device in case of power cut .
