Wire Rope Winch(WSH-A)

Name: Wire Rope Winch(WSH-A)
Brand: Feidiao
SKU: 120565299
Availability: InStock

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Anhui, China

Brand Name:

Feidiao

Model Number:

WSH-A

Tongling Shendiao Machinery Manufacturing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Anhui, China

Brand Name Feidiao

Model Number WSH-A

Specifications

WSH-A Wire Rope Pulling Hoist Features:
1)Capacity from 0.8T to 3.2T
2)High quality aluminium body
3)Overload protection

WSH-A Wire Rope Pulling Hoist Features:
1)Capacity from 0.8T to 3.2T
2)High quality aluminium body

3)Overload protection system ensures safety in operation

4)Tube handle length is adjustable, so it is very convenient to regulate the hand force according to the lifting force.

5)Widely used for lifting, pulling, tensioning, and tightening in many areas

6)Easy operation, convenient maintenance

7)Get Certificate of ISO9001

8)The static test is 4 times of capacity, and running test is 1.5 times of capacity.

Model	WSH-0.8A	WSH-1.6A	WSH-3.2A
Rated capacity t	0.8	1.6	3.2
Standard lift m	20	20	20
Test load t	1.2	2.4	4
Rated forward handpower N	341	400	438
Rope diameter mm	φ8.3	φ11	φ16
Rated forward travel(Swing it front and backward) mm	≥52	≥55	≥28
Net weight kg	6.4	12	23
