Help CenterChina Professional Manufacturer Supply 10mm2 AAAC Bare Conductor
Related Products
-
Professional Top Quality 100mm2 ACSR Cable For SaleUS$ 0.1 - 1MOQ: 1 Kilometer -
Professional Top Quality ACSR Conductor AWG80 For SaleUS$ 0.1 - 1MOQ: 1 Kilometer
-
Hot Selling Product ACAR Cable With Reasonable PriceUS$ 0.1 - 1MOQ: 1000 Meters
-
Hot Selling Product ACAR Bare Aluminum CableUS$ 0.1 - 1MOQ: 1000 Meters
-
China Professional Manufacturer Supply Bare Conductor AAACUS$ 0.1 - 1MOQ: 1000 Meters
What are Our Advantages of AAAC Compared With Other Manufacturers?
AAAC (All Aluminum Alloy Conductor) referred to have higher strength but lower conductivity than pure aluminum. Being lighter, alloy conductors can sometimes be used to advantage in place of the more conventional ACSR; Having lower breaking loads than the latter, their use becomes particularly favourable when ice and win loadings are low.
We can supply this conductor according to different recognized standards, such as BS EN50182, IEC61089, ASTM B399DIN 48, customer special specification also can be satisfied.
The data sheets below show the most common standards, British standard and IEC standard.
BS EN 50182:2001
| Code Name | Stranding&wire diameter | Approx Overall diameter | Total area | Weight | Breaking Load | DC Resistance at 20 | Current Rating |
| mm | mm | mm 2 | Kg/km | KN | Ohm/km | A | |
| Box | 7/1.85 | 5.55 | 18.8 | 51.4 | 5.55 | 1.748 | 93 |
| Acacia | 7/2.08 | 6.24 | 23.9 | 64.9 | 7.02 | 1.3828 | 110 |
| Almond | 7/2.34 | 7.02 | 30.1 | 82.2 | 8.88 | 1.0926 | 128 |
| Cedar | 7/2.54 | 7.62 | 35.5 | 96.8 | 10.46 | 0.9273 | 132 |
| Deodar | 7/2.77 | 8.31 | 42.2 | 115.2 | 12.44 | 0.7797 | 148 |
| Fir | 7/2.95 | 8.85 | 47.8 | 130.6 | 14.11 | 0.6875 | 161 |
| Hazel | 7/3.30 | 9.9 | 59.9 | 163.4 | 17.66 | 0.5494 | 184 |
| Pine | 7/3.61 | 10.8 | 71.6 | 195.6 | 21.14 | 0.4591 | 204 |
| Holly | 7/3.91 | 11.7 | 84.1 | 229.5 | 24.79 | 0.3913 | 222 |
| Willow | 7/4.04 | 12.1 | 89.7 | 245 | 26.47 | 0.3665 | 233 |
| Oak | 7/4.65 | 13.95 | 118.9 | 324.5 | 35.07 | 0.2767 | 272 |
| Mulbery | 19/3.18 | 15.9 | 150.9 | 414.3 | 44.52 | 0.2192 | 319 |
| Ash | 19/3.48 | 17.4 | 180.7 | 496.1 | 53.31 | 0.183 | 354 |
| Elm | 19/3.76 | 18.8 | 211 | 579.2 | 62.24 | 0.1568 | 385 |
| Poplar | 37/2.87 | 20.1 | 239.4 | 659.4 | 70.61 | 0.1387 | 414 |
| Sycamore | 37/3.23 | 22.6 | 303.2 | 835.2 | 89.4 | 0.1095 | 487 |
| Upas | 37/3.53 | 24.7 | 362.1 | 997.5 | 106.82 | 0.0917 | 527 |
| Yew | 37/4.06 | 28.4 | 479 | 1319.6 | 141.31 | 0.0693 | 629 |
| Totara | 37/4.14 | 29.42 | 498.1 | 1372.1 | 146.93 | 0.0666 | 640 |
| Rubus | 61/3.50 | 31.5 | 586.9 | 1622 | 173.13 | 0.0567 | 716 |
| Sorbus | 61/3.71 | 33.4 | 659.4 | 1822.5 | 194.53 | 0.0505 | 760 |
| Araucaria | 61/4.14 | 37.3 | 821.1 | 2269.5 | 242.24 | 0.0406 | 842 |
| Redwood | 61/4.56 | 41 | 996.2 | 2753.2 | 293.88 | 0.0334 | 920 |
What are Our Applications of AAAC Compared With Other Manufacturers?
Our caring service, manufacturing careful Heart price, customers at ease.
"Customer-oriented", provides a full range of quality services for our customers;
"Service core" most valuable customers tailored products;
"Focus on quality, full-service customers!
Equipment:
1. How many years has Henan Jiapu Cable Group been in production?
Founded in October 1998 by Mr. Gu, our facipty has three separate manufacturing workshops within its 100,000-sq.-ft. building. In 2012, we operates in a new 666,000 sq. foot state-of-the-art facipty in Xiaodian Industry Park.,Xinxiang, Henan ,China.
2. What kind of certifications do you have?
SABS, CE, ISO9001-2000, SGS.
3.Which markets do you involve mainly in?
Our products have been exported mainly to Africa, Middle East, South-east Asia, South America,Central America,North America, Europe ,Austrapa, etc.
4. Which standards do you comply with when you produce the electrical wires and cables ?
We are able to produce electrical wires and cables based on GB, JB, IEC, BS, DIN, ASTM, JIS, NF, AS/NZS, CSA, etc. Meanwhile, we can design and manufacture the cables according to the samples and technical specification the customer supply.
5. What is the min.order quantity ?
It depends on the type and size of electrical wires and cables. For some small electrical wires, 100 meters can be accepted .But for the power cables with medium or high voltage, that should comply with the property of installed equipments. Anyhow,we will try our best to solve the problem and meet with the requirement If you have special request.
6. What is the production capacity per week or per month ?
For the bare conductor, we can finish 3000 tons within one month. For power cables, that depends on the type and size. The total output value per month is approx. USD3,000,000.00 for insulated aluminum cables and that is approx. USD8,000,000.00 for insulated copper cables.
7. Do you supply the customers with installation service in foreign country ?
We don’t have professional installation teams in foreign country.But if that is necessary, we will recommend our partners to cooperate with you.
8. Can't find what we're looking for in your catalogue?
Call one of our experienced sales reps at 0086 371 68665329. They can quote you on any type of products you need, or you can send your inquiry and question to our email.
