Home > Electrical & Electronics > Power Supply & Distribution > Switching Power Supply > CE RoHS Approved Factory Outlet 100a Power Supply 24v

CE RoHS Approved Factory Outlet 100a Power Supply 24v

Name: CE RoHS Approved Factory Outlet 100a Power Supply 24v
Brand: WeHo
SKU: 120503263
Availability: InStock

CE RoHS Approved Factory Outlet 100a Power Supply 24v thumbnail-1

CE RoHS Approved Factory Outlet 100a Power Supply 24v photo-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Brand Name:

WeHo

Model Number:

SCN-1000-12

Output Power:

Other, >500W

Contact Supplier Request Quote Chat Now

Zhejiang Weihao Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo Shanghai Guangzhou Hangzhou

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name WeHo

Model Number SCN-1000-12

Output Power Other, >500W

Output Type Single

Output Voltage 12V

Output Frequency 50Hz

Output Current 80A

transproting:according to customer's requirements

100a power supply 24v
1.CE RoHS approved
2.2 years warranty
3.875 efficiency
4.100% test

100a power supply 24v

1.Specification:

Model Performance	SCN-1000-12	SCN-1000-13.5	SCN-1000-15	SCN-1000-24	SCN-1000-27	SCN-1000-48
DC Output Volta	12V	13.5V	15V	24V	27V	48V
Output voltage tolerance(Note 2)	1%	1%	1%	1%	1%	1%
Rated output current	50A	44A	40A	25A	22A	12.5A
Output current range	0-40A	0-36A	0-32A	0-20A	0-18A	0-10A
Ripple and noise(Note 3)	240mVp-p	240mVp-p	240mVp-p	240mVp-p	200mVp-p	300mVp-p
Inlet stability(Note 4)	0.5%	0.5%	0.5%	0.5%	0.5%	0.5%
Load stability(Note 5)	1%	0.5%	0.5%	0.5%	0.5%	0.5%
DC output power	600W	600W	600W	600W	600W	600W
Efficiency	84%	84%	83%	85.5%	86.5%	87%
DC voltage adjustable range	10-13.2V	12-15V	13.5-18V	20-26.4V	24-30V	41-56V
Input voltage range	88~132VAC/176~264VAC CHOOSE BY SWITCH 47~63Hz;124~370VDC
Input current	7A/115V 3.5A/230V
Surge Current	0.95/100~240VAC
Leakage Current	18A/115V 36A/230V
Overload protection	<3.5mA/240VAC
over-voltage protection	105%~135% type:FOLDBACK cut off output reset:Automatic recovery
High temperature protection	13.8~16.2V	15.5~18.2V	18~21V	27.6~32.4V	31~36.5V		57.6~67.2V
temperature coefficient	RTH1 OR RTH2>=55C FAN ON,<=45C FAN OFF,>=70C cut off output
Start-up,upper,rentention time	0.03%C(0~50C)
shock resistance	1.5s,50ms,20ms
Withstand	10~500Hz,2G 10min./1circle,time:60min.,axes
Insulation Resistance	Input to Output Isolation:3KVAC,input&shell:1.5KVAC output &shell:0.5KVAC
work Temperature/ humidity	Input to Output Isolation,,input&shell, output &shell:500VDC/100M Ohms
Storage Temperature,temperature	-10C~+50C,20%~90%RH
Outline dimension	-20C~+85C,10%~95%%RH
Weight	29113268mm shell:910
Safety standards	5Kgs
EMC Standard	UL1950,TUV EN60950
Model Performance	CISPR22(EN55022),IEC1000-42,3,4,5,6,8,11 IEC100-3-2
