Our company can electroplate silver on copper alloy which diameter cannot exceed 2.50mm.
Then the wire can be drawing and annealing.
- Silver plated silver-copper alloy wire
Product Specification:Q/DW04—2010
Type: SCAS
Application: This wire can using in +200℃ situation with high flexibility performance
Data sheet: shown in table 1
Table 1:
Diameter mm |
Tolerance |
1.0-1.1 |
±0.040 |
1.11-1.8 |
±0.045 |
1.81-2.5 |
±0.050 |
- Silver plated CCA wire: Product Specification: Q/DW05-2010
Type: CCAY
Application: This wire can using in +200℃ situation with high frequency performance,
low weight, easy welding, mainly using in Hi-Fi wire and cable of sound box.
Product series:
CCAY (10A) Silver plated CCA wire (the volume rate of copper layer is 10% soft CCA)
CCAY (10H) Silver plated CCA wire (the volume rate of copper layer is 10% hard CCA)
CCAY (15A) Silver plated CCA wire (the volume rate of copper layer is 15% soft CCA)
CCAY (15H) Silver plated CCA wire (the volume rate of copper layer is 15% hard CCA)
- Data sheet:
1, Wire diameter: 0.127-2.05mm
2, Tensile strength of break (Mpa): Type H: 193-205 Type A: 138-172
3, Elongation of break (%): Type H: 1.0 (min) ;Type A: 5—15(max)
4, Resistivity:
Type H: No more than 0.02743Ωmm2/m
Type A: No more than 0.02676Ωmm2/m
5, Thickness of the silver layer is 1.0μm, but we can add it based on the customer,s requirement.
6, The CCA must according to the specification SJ/T1123-2000 idt ASTM B566:1993
7, Packing: Based on the customer,s requirement.
