Quick Details
| Place of Origin: | Model Number: | Material: | |||
| Size: | Number of Cells: | Max. Power: |
Packaging & Delivery
| Packaging Detail: | Wooden pallet with paper cartons, or wooden carton, or according to your requirements |
| Delivery Detail: | 15 days, if samples, 7 days |
Specifications
1.with IEC, TUC, CE, ISO, CEC
2.30-year warranty
3.low price
48v- 250w mono solar cell panel China Solar Panel with 8*12
Description:
1.high conversion efficiency
2.sealed with high transparency low-iron tempered glass, anti-aging EVA, high insulation TPT.
3.withstand high wind pressure and snow load.
4.with IEC61215/61730, TUV, CE, ISO
Warranty:
1) 5 years for material & workmanship;
2) 12 years for 90% power output;
3) 25 years for 80% power output.
MOQ: 50pcs
Delivery Time: 10-20 days after order confirmation
Payment Terms: T/T 30% in advance, and the balance should be paid before delivery.
Packing: Wooden carton or pallet packing
Module Type CS-250M
Maximum Power at STC (Pmax) 250Wp
Maximum Power Voltage (Vmp) 48.3V
Maximum Power Current (Imp) 5.18A
Open-circuit Voltage (Voc) 57.9V
Short-circuit Current (Isc) 5.53A
Dimension mm) 1580*1056*45
Module Efficiency (%) 15%
Operating Temperature(°C) -40°C~+90°C
Maximum System Voltage(V) DC 1000V(TUV) / DC600V(UL)
Maximum Rated Current Series(A) 15A
Power Tolerance 0~+3%
Temperature Coefficients of Pmax (-0.45±0.05)%/°C
Temperature Coefficients of Voc (0.05±0.01) %/°C
Temperature Coefficients of Isc (-0.35±0.02)%/°C
NOTC(°C) (47±2)°C
Temperature Coefficient:
| NOCT (ºC) | 47 ± 2 |
| Temperature Coefficient of Pm (%/ºC) | -0.45 ± 0.05 |
| Temperature Coefficient of Isc (%/ºC) | 0.05 ± 0.01 |
| Temperature Coefficient of Voc (%/ºC) | -0.35 ± 0.02 |
