Home > Electrical & Electronics > Power Supply & Distribution > Switching Power Supply > Wenzhou Supplier 50W Single Output Switching Power Supply

Wenzhou Supplier 50W Single Output Switching Power Supply

Name: Wenzhou Supplier 50W Single Output Switching Power Supply
Brand: SAKO
SKU: 120333169

Wenzhou Supplier 50W Single Output Switching Power Supply thumbnail-1

Wenzhou Supplier 50W Single Output Switching Power Supply photo-1

US$ 5 - 10 MOQ: 1000 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

SAKO

Model Number:

SKK-S-50W

Contact Supplier Request Quote Chat Now

Sako Electrical Group Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo or Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name SAKO

Model Number SKK-S-50W

Output Power 51 - 100W

Output Type Single

Input Voltage 220V

Output Voltage 5V,12V,15V,24V

Output Frequency 50/60Hz

Output Current 10A,4.2A,3.4A,2.1A

Specifications

1.SKK-S series single output switching power supply
2.Input:88-132VAC/176-264VAC
3.Output:5V10A,12V4.2A,15V3.4A,24V2.1A
4.OEM

SKK-S series single output switching power supply,adopt to PWM control mode,design according to high reliability, high anti- interference,wide applicability,it can running continous & safety.

FEATURES

1.Small volume,light weight

2.100% full load burn-in test

3.Soft start circuit,limiting AC surge current

4.International AC input range

5.Short circuit,overload,over voltage protections

6.High efficiency,low working temperature,long life

APPLICATION

widely used to air purifier,security systems,communicatons,electronics,etc.

TECHNICAL PARAMETER

INPUT

Voltage range:88-132VAC/176-264VAC 47-63Hz

AC current:1.3A/115V 0.65A/230V

Inrush current:Cold start 18A/115VAC 36A/230VAC

Leakage current:<1mA/240VAC

OUTPUT

Setup,rise,hold up time:200ms,100ms,20ms at full load

PROTECTION

Overload:105%-150% Shut down o/p voltage, re-power on to recover

ENVIRONMENT

Working temperature & humidity:-10°c to +60°c;10%-95% RH

Storage temperature & humidity:-20°c to +85°c;10%-95% RH

Vibration:10~500Hz,2G 10min./1cycle, period for 60min, each along X, Y, Z axes

SAFETY

Withstand voltage:I/P-O/P:3KVAC I/P-O/P:1.5KVAC O/P-FG: 0.5KVAC

Isolation Resistance:I/P-O/P, I/P-FG, O/P-FG:500VDC/100MΩ

STANDARDS

Safety standards:Design refer to GB4943,UL60950,EN60950

EMC standards:Design refer to EN55022,EN61000-3-2,EN61000-3-3,EN55024

SPECIFCATION

MODEL		SKK-S-50-5	SKK-S-50-12	SKK-S-50-15	SKK-S-50-24
OUTPUT	DC Voltage	5V	12V	15V	24V
	Voltage Tolerance	±2%	±1%	±1%	±1%
	Rated Current	10A	4.2A	3.4A	2.1A
	Current Range	0-10A	0-4.2A	0-3.4A	0-2.1A
	Rated Power	50W	50.4W	51W	50.4W
	Ripple & Noise	70mVp-p	80mVp-p	80mVp-p	100mVp-p
	DC Adjustment Range	+10,-5%	±10%	±10%	±10%
	Setup, Rise, Hold Time	200ms,100ms,20ms at full load
INPUT	Voltage Range	88~132 VAC/176~264 VAC 47~63Hz selected by switch 240~370 VDC
	AC Current	1.3A/115V 0.65A/230V
	Efficiency	72%	77%	77%	82%
	Inrush Current	Cold start 18A/115VAC 36A/230VAC
	Leakage Current	<1 mA/240VAC
PROTECTION	Over Load	110%~150%
		Protection: Shut down o/p voltage, re-power on to recover
ENVIRONMENT	Working Temp., Humidity	-10°C~+60°C;20%~90 %RH
	Storage Temp., Humidity	-20°C~+85°C;10%~95%RH
	Vibration	10~500Hz,2G 10min./1cycle, period for 60min, each along X, Y, Z axes
SAFETY	Withstand Voltage	I/P-O/P:3KVAC I/P-O/P:1.5KVAC O/P-FG: 0.5KVAC
	Isolation Resistance	I/P-O/P, I/P-FG, O/P-FG:500VDC/100MΩ
STANDARD	Safety Standard	Design refer to GB4943,UL60950,EN60950
	EMC Standard	Design refer to EN55022,EN61000-3-2,EN61000-3-3,EN55024
OTHERS	Weight	0.47Kg
	Packing	48pcs/23.5Kg/0.042CBM
NOTE	1.All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25°C of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12″twisted pair-wire terminated with a 0.1μ & 47μ parallel capacitor. 3.Tolerance: includes set up tolerance, line regulation and load regulation.
