Communication installation cableJ-Y(St)Y
Communication installation cable
J-Y(St)Y
1. APPLICATION
For signal and communication transmission, for instalation in dry and damp operating places in
and under finery as well as in the outside area.
2. JACKET
- material : PVC accordance to VDE0207
- overall diameter: 5,2mm
- color : grey RAL 7032
3.CONDUCTORS (BASIC WIRE)
construction : solid bare copper, 3 x 2 x 0,6mm, 2 cores to a pair, 6 cores in layers
copper drain wire 0,4mm
- PVC accordance to VDE 0207
- O.D.: 1+- 0,05 mm
Twisted pairs in layers wrapped with foil shield (screen) Al/Polyester tape
4. ELECTRICAL CHARACTERISTIC
Testing voltage: 800V
Insulation resistance: 100 MOhm/km at 20°C
Mutual capacitance at 800Hz max.: 120nF/km
Operating voltage peak value max: 300V
5. MECHANICAL AND PHYSICAL CHARACTERISTIC
- Bending radius: min 15 x OD
- temperature range -15°C to +70°C
In accordance with RoHS directive
