Home > Metallurgy, Mineral & Energy > Non-ferrous Metal & Products > Titanium > ASTM Titanium Tube Pipe Fittings 12mm

ASTM Titanium Tube Pipe Fittings 12mm

ASTM Titanium Tube Pipe Fittings 12mm thumbnail-1
ASTM Titanium Tube Pipe Fittings 12mm photo-1
US$ 15 - 40 MOQ: 50 Kilograms
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Channel
Model Number:
titanium tube
Contact Supplier Request Quote Chat Now
Zhangjiagang Channel Intl Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai for titanium tubes
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name Channel
Model Number titanium tube
Material titanium
Outer Diameter 3-314mm
Length ≤9000mm
Standard ASTM
Application Industrial,medical,condensers,etc
Technique Seamless
Grade titanium, Pure titanium and titanium alloy gr1,gr2,gr5,gr9,gr12
Wall Thickness 0.2-30mm
Inside Diameter 2.5~150mm
Product Description

ASTM titanium tube pipe fittings 12mm

 Titanium mian feature:

The density of titanium is 4.506-4.516g/cm^3, melting point is 1668, boiling point is 3535. Therefore Titanium have low weight, excellent high strength and nonmagnetic festures, low density, excellent corrosion resistance features, high specificate strength and high temperature resistance features, so it is widely used in chemical industry field, medical field, electronics manufacture, mechanical parts field, automobile industry, and aerospace field, etc.

Product detail:

Product Name
Titanium  tube/tubes/pipe/pipes/tubing
Standard
ASTM B348, ASTM B381, ASTM F67, ASTM F136, ASTM F1295, ASTM F1713, ASME, AMS
Material
Gr1, Gr2, Gr3, Gr5, Gr7, Gr9, Gr11, Gr12, etc


Length                                   <6000mm
Size(mm)
Diameter                                     8-200
Section shape
Round/ Square
Certification
ISO9001, SGS,
Surface Treatment
pickling, polished, bright finish etc.
Feature
1.Low Density and High Strength
2.Excellent Corrosion Resistance
3.Good resistance to effect of heat
4.Excellent Bearing to cryogenic property
5.Nonmagnetic and Non-toxic
6.Good thermal properties
7.Low Modulus of Elasticity
Advantages
1. First-class technonlgy and the rigorous work attitude
2. We have the most professional team to solve all kinds of the problems you have
during the manufacturing process and provide your pressure vessel drawing for free
if you need.
3. Low purchasing cost for repetitive orders in the long-run as our
    performance/price ratio is higher.
4. Never be backorder.
5. Excellent customer service policies on repair/exchange/refund.
6. Serving both domestic and overseas customers with various
    requirements for 22 years.



 Chemical Propeties:




N
C
H
Fe
O
Al
V
Pa
Mo
Ni
Ti
Gr1
0.03
0.08
0.015
0.20
0.18
/
/
/
/
/
Bal
Gr2
0.03
0.08
0.015
0.30
0.25
/
/
/
/
/
Bal
Gr5
0.05
0.08
0.015
0.40
0.20
5.5~6.75
3.5~4.5
/
/
/
Bal
Gr7
0.03
0.08
0.015
0.30
0.25
/
/
0.12~0.25
/
/
Bal
Gr9
0.03
0.08
0.015
0.25
0.15
2.5~3.5
2.0~3.0
/
/
/
Bal
Gr12
0.03
0.08
0.015
0.30
0.25
/
/
/
0.2~0.4
0/.6~0.9
Bal



 Mechanical properities



Grade

 Tensile Strength(Min)



Yield Strength(Min)

Elongation in 4D, Min, %

Reduction of area, Min, %



Kis

Mpa

Kis

Mpa





Gr1

35

240

25

170

24

30

Gr2

50

345

40

275

20

30

Gr3

72.5

500

55

380

18

30

Gr4

85

586

70

483

15

25

Gr5

130

895

120

828

10

25

Gr7

50

345

40

275

20

30

Gr9

90

620

70

483

12

25

Gr11

35

240

25

170

24

30

Gr12

70

483

50

345

18

25




Production Flow



Packaging & Shipping



FAQ



•Q1. What is your Payment Terms?
•
•A1. We usually suggest T/T(Prepaid & Balanced),L/C,Paypal,Escrow,but other ways will be no problem,like  ,Western Union, Money Gram.  All will be talked with you before your order.

• Q2. What is the MOQ of your product?
•
•A2. Usually our MOQ is 20KG,But we can sell as per your quantity(even less than 20KG) if they are in ready stock.Anyway,just contact us even it is a very small order.Because all can be talked openly.
•
• Q3. Do you offer free sample?
•
•A3. Usually our sample is free but we wish our customer to pay the freight.When you put us the batch order,we will return the sample freight to you.
•
• Q4. What is your Supply Ability?
•
•A4. 30 tons per month is no problem now.
If you can not find the product you need, See here!
please write the following information, We will send you the product details and quotation.

1.Material: Titanium, Stainless steel,Aluminium etc.
2.Form: plate, sheet, bar, rod, tube,wire,etc.
3.Dimension: thickness,  width, length or diameter.
4. Standards: ASTM, ASME, AMS, BS, BT, GOST, etc.
5.If you can supply the quantity and using, it's better for supplying quotation
