ASTM 304/316 cold drawn stainless steel welding pipe
steel welding pipe
Features:
1) Production Standard :ASTM A269;Enterprise Standard
2) Material of commonly used stainless steel:TP304, TP316L; Material of other stainless steel: TP304L
3) Product applications and applicable field: refrigerating equipment, evaporators, gas/liquid conveying, condensers, beverage machinery
4)General product status at delivery: semi-hard status/bright annealing soft status
5) Specification range:outer diameter:6mm-19mm;
6) Annual production capacity: 600 tons
Note: We aslo have had a history of producing stainless steel tube in coil for well over a dozen years and we have two lines for the production of continuous weldingpipes. On the basis of complete equipment and leading technology, the company has aslo introduced world first-class brigt annealing technology, which makes it possible to conduct stainless steel pipe online softening treatment. Besides, we aslo have testing & inspecting facilities for flattening, tube end expansion, cold benging as well as for hardness, tensile and 100% airtightness tests. With reliable quality ang reasonable prices, 80% of our coil pipe products are exported to countries all over the world.
Coil Pipe Technical Parameters Set By The Manufacturer:
1) Stainless Steel Pipe Measurement Range:outer diameter: 6-19mm; wall thickness: 0.41-1.5mm; the measurement tolerance as per ASTM A269
2) The outer diameter of the coil pipe>500mm; the inner diameter of the coil pipe<1000mm
3) The height of the coil pipe:200mm-400mm
4) Max.length of each coil:<1000M min.length of each coil:>6m
5) General delivery length:200m-800m
6) Physical properties of bright-annealed coil pipe:A. ratio of elongation no less than 55% B. surface hardness no greater 170HV C. tensile strength no less than 550N/MM2 D. yield strength no less than 220N/MM2 E. bending angke>1800; mon.bending radius<1.5*pipe diameter
7) Physical properties of general coil pipe (without bright annealing):A. ratio of elongation no less than 35% B. surface hardness greater than 180HV C. tensile strength>600N/MM2 D. yield strength>280N/MM2 E.bending angle>900; bending radius>2*pipe diameter
8) Pressure resistance property:take 8*0.5*c coil pipe as an example, the work pressure to be borne by the inner wall is no less than 60BAR
Detailed Product Description
