In order to eliminate any misunderstanding, you are requested to provide below information for your order:
1) Please inform the phase, voltage and frequency of the electricity you connect to the welding machine.
2) Please inform the current,thickness of materials , kinds of material will welding.
THANK YOU!
About Supplier
Brand Name: EP WELDING (or your brand with intellectual rights)
Manufacturer: CHENGDU EXPERT TECHINOLOGY CO. LTD as its web address www dot expert-welding dot com, to track your order by phone you may contact our sales by adding the same ID number +86 15889658730 via WHATSAPP, VIBER or WECHAT.
CE,CCC DC MMA single phase small inverter ARC welding machine
introduction of small mig/mag welder
MAIN FEATURES | |
√ |
Simple and easy, multi welding process MIG,MMA (Stick) and lift TIG(optional). |
√ |
Arc stability and control. |
√ |
Full digital Synergic control of cycle. |
√ |
Equipped with Imported IGBT, energy saving. |
√ |
Equipped with build-in wire feeder, support 0.6 or 0.8mm wire welding. |
√ |
Equipped with reverse polarity for special wire Gasless Welding. |
√ |
The MMA (Stick) welding process is equipped with the functions Hot Start, Arc force and Anti Sticking. |
√ |
With over-loading and over-heating protection. |
√ |
Smaller, lighter and portable, this equipment is protected by a solid metal casing. |
√ |
Supplied complete with Mig Welding Torch, Tig Welding Torch (optional), MMA (STICK) Welding Torch, Earth Cable and clamp. |
Parameter | |||
Item |
Unit |
||
Power Supply |
Power Frequency |
Hz |
50/60 |
Rated input voltage |
V |
220 |
|
Allowable operating voltage range |
% |
±15 |
|
Fuse |
A |
40 |
|
Input power cable |
|
3*1.5mm2*2.2 meter |
|
Performance |
Rated input capacity |
KVA |
5.5 |
Rated input current |
A |
25 |
|
No-load voltage |
V |
28(MIG)/60(MMA) |
|
Output current |
A |
30-150(MIG) |
|
Duty cycle |
% |
35(130A MIG) (120A MMA) |
|
100% Duty cycle |
A |
77 |
|
Efficiency |
η |
85% |
|
Power Factor |
Cosφ |
0.93 |
|
Features |
Technique |
Inverter IGBT |
|
Process |
MMA ,MIG/MAG, optional for LIFT TIG |
||
HF arc start |
yes |
||
Recommend welding thickness |
mm |
0.5-1.5 |
|
General |
Quick plug |
10-252 to 1120 |
|
Protection |
over heat |
||
Cooling mode |
gas -cooled |
||
Enclosure/Standards/Approvals |
Insulation class |
level |
H |
Protection class |
IP |
IP21S |
|
Net weight |
kg |
8(include torch) |
|
Machine size L×W×H |
cm |
35cm*27cm*17cm |
|
Standard IEC 60974-1 |
|
yes |
|
Standard accessory:
1 |
Earth clamp |
200A |
pcs |
1 |
2 |
Earth wire |
10MM2*1.2M |
pcs |
1 |
3 |
Torch |
10MM2(pipe 0.8, nozzle)(Length 2.4M) |
pcs |
1 |
5 |
nozzle |
φ0.6 |
pcs |
1 |
6 |
Manual |
|
pcs |
1 |
7 |
Quick plug |
|
pcs |
1 |
1. Warranty: Free 1 year warranty for all welding machine;
2. Quick response: Experienced professional sales support within 24hours response for your questions and product inquiry;
3. Spare parts: 1 set of free spare parts(in our standards) will be provided for replacement for every 20pcs machines;
4. Technical Support online: Maintenance manual or video service, We provide online support according to your picture or video feedback. Customized after-sales service according to different conditions;
5. Training: Free onsite Product training is available at our factory if client request.
