Specifications
1.High quality2.Light weight
3.Easy to install
4.Fireproof and soundproof
5.Pollution-free
B.R.D panels fireproof and soundproof PU sandwich panel
1) About us
Henan B.R.D New Material Company, Ltd is belonging to Henan Bao Yuan Steel Group, which is a high-tech group corporation integrating iron /steel trade, steel structure design, research and development, and new energy-saving material as one entity. It was established in 1995.
The main products are pre-painted steel coils, galvanized steel coil, strip steel, C steel processing, polyurethane energy-saving sheet, composite panel, steel structure design, research and development, manufacture, construction. It has an annual capacity to produce 150,000 tons of steel structure series products, 200,000 tons of polyurethane pre-painted steel coil and 150,000 galvanized steel coil.
2) About products
PU sandwich board/panel
PU Sandwich panel (Polyurethane sandwiched panel )is composed of 2 layers of weather-proof colored steel sheets and jetted the hard forms of polyurethane between 2 layers which feature fireproof materials. It is suitable for the various roofs and walls referring to the large-size factory buildings, storages, exhibition halls, gymnasiums, freezing stores, purifications workshops, etc, which features temp-keeping, heat insulation, weight-bearing, weatherproof with the rich colorfulness and good appearance.
Steel Thickness |
0.2~0.6mm |
Panel thickness |
50/75/100/125/150/200 mm |
Effective width |
(1) 950/mm ---for roof (2) 950/1150mm---for wall or ceiling |
Length |
According to customer's request, less than 11.8m |
Materials |
Inner is Rockwool, two sides is Color steel tile |
Structure |
three layers: (1)upper layer is steel sheet, (2)the inner layer is PU sandwich, (3)the bottom layer is also steel sheet |
Rockwool density |
30-50(kg/m³),etc |
color |
blue, white grey, or other colors . |
Parts |
Steel line for easy connect one by one Film covering in order to protect the steel of panels |
lifetime |
15~20 years |
Character |
Light in weight, heat insulation, fireproof and water proof, environmental |
Use |
various roofs and walls referring to the large size factory buildings, storages, exhibition halls, gymnasiums ,etc |
Packing |
Packed by shipping Container or according to your demands |
3) Characteristics
•Easy to install, shorten the construction period.
•Protect environment, sandwich structure with antioxidant surfaces.
•High performance in heat insulating, can be served in both high and low temperature environment.
•Fireproof, meet the National standard, makes building safe.
•Soundproof, makes a quieter environment.
•No need to leave space for insulation material installing, so that the story height can be reduced.
•Long service life up to 20 years, very low cost in wastage and maintenance.
•Nice appearance.
4) Usage
Warehouse,
Factory
School
Office building
Carport
Supermarket,
Civilian facilities,
Gym,
Culture and entertainment centers.
Cold storage plant
Our advanced assembly line
