Home > Manufacturing & Processing Machinery > Paper Machinery > Paper Making Machine > Scrapbook Cutting Plotter With 1360MM Paper Feeding Small Cutting Plotter

Scrapbook Cutting Plotter With 1360MM Paper Feeding Small Cutting Plotter

Name: Scrapbook Cutting Plotter With 1360MM Paper Feeding Small Cutting Plotter
Brand: YINGHE
SKU: 120108747
Availability: InStock

Scrapbook Cutting Plotter With 1360MM Paper Feeding Small Cutting Plotter thumbnail-1

Scrapbook Cutting Plotter With 1360MM Paper Feeding Small Cutting Plotter photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Brand Name:

YINGHE

Model Number:

YHS720

Voltage:

AC160V-AC260V 50-60HZ

Contact Supplier Request Quote Chat Now

Guangzhou Yinghe Electronic Instruments Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name YINGHE

Model Number YHS720

Voltage AC160V-AC260V 50-60HZ

Dimension(L*W*H) 1120*386*330mm

Weight 26kg

Certification CE

Warranty 12 month from delivery date

Specifications

1.High cutting speed
2. Accu-Aligning System for contour cutting(AAS)
3.Auto 4 point tracking
3.CE certification
4.8M memory

Product Description

Guangzhou YHS-720 720mm contour cutting plotter

Specification:

1. The specialized industry modelling and mechanism design ,the outword appearance more smooth & natural,the structure more scientific and strong.

2. The wholly aviation aluminium molding body,which make sure more stable function under hign speed working.

3. The imported punctures paper-roll with more friction force and more working life ,and without any posiible deviation after long media cutting.

4. The whole-steel linear bearing pen-vehicle,with bigger cutting pressure and can be adjustable easily,with good heat dispersion.

5.The DSP processor,with more quickly operating speed,subdivieds the constant flow with low noise and stable system operation.

6.The worldwide first technology draws(or cut)with negtive direction function,save more cost and bring more using value for user.

7.The standard USB connection ,the data transmission is stabler.Meanwhile with the U Flash memoray can used for output directly.

8. Built-inside closed compensation,acute angle compensation ,which can be used directly from coredraw,CAD or other design software.

9. The LED display with light backsie,also easily changed between Engliah and Chinese,with more simply operation.

Performence features:

1. The Japan imported New Micro-Control Technology,Untel USP Controller,Japan High-Precision steel Axes&64 Sub-Dvide motor,just with 48dp low working noise.

2. Up to 1000mm per second cutting speed ,especially for Y axis 2020mm per second media-sending max speed.

3. Up to 0.0191mm/step(0.00073")mechanical resolution(DSP),0.127mm(0.00049")repeating resolution ensure high precision output.

4. Up to 600 gram cutting force for making sure any media cutting.

5. Up to 0.8mm(0.0315")thicknes cutting media.

6. Guranteed 10 meter tracking with high precision.

7. Newest data transmission Interface:USB&U Flash

Parameter:

Model	YHS-720	YHS-850	YHS-1100	YHS-1350
Max. paper feeding width	720mm	800mm	1100mm	1350mm
Max.cutting width	620mm	750mm	1000mm	1250mm
Max. cutting speed	Whole cutting:1000mm/s;Y axis max cutting 2010mm/s
Cutting Force	10-600g
Memoray	512k can be update to 8M memorary
Mechanical resolution	0.0191mm/step
Repeating precision	0.127mm(0.00049")
Interface	RS-232USB or U Flash
Language Format	DM/PL/HPGL
Power Supply	AC160V-AC260V 50-60HZ
Driving System	DSP 64 Sub-Dvide high-precision step motor
Working Enviromental Temperature	0-35°C
Working Enviromental Humidity	5%-95% no coagulate water
Display	The LED Display with Chinese and Enlish
Packing Size	1120386330mm	1250386330mm	1500386330mm	1750386330mm
Gross Weight	26kg	29kg	33kg	36kg
Optional Software	Artcut/Flexi Sign(Optional)
