design and customize the portable vehicle CO gas alarm
- 5000 Piece / Pieces per Month
- beijing
- Credit Card
- ODM offer for portable biogas detector with infrared CH4, CO2 sensors and electrochemical H2S, O2 sensors
- Data logging Infrared Multi 4 Gas Detector for CH4, CO2, CO, O2, gas monitor
- portable automotive exhaust emission gas detector with 5 years lifetime co sensor and removeable battery
- hand held CO gas meter with high quality, long lifetime and battery operation
- portable vehicle automobile exhaust gas detecting alarm and co exhaust gas analyzer meter for driver's safety
- portable domestic carbon monoxide gas alarm with battery power supply and 5 years lifetime
Product Details
Place of Origin: | Beijing, China | Brand Name: | OEM | Model Number: | SA-V4 |
Usage: | Personal |
Packaging Details
paper carton
Product Description
This vehicle co gas alarm can detect the co gas concentration in the car environment, and make sound and light alarms when the ambient concentration is over the warning values, then prevent users from co gas damages. ( detailed alarm values, please see the Alarm concentration)
This device couldn’t be used to detect the natural gas (methane ), propane, butane or other combustible materials. Designed by professional engineers, its unique and attractive appearance is harmonious with the whole vehicle cars.
Technical specification
n Gas sensor:
Japan’s NEMOTO sensor, good quality, more 5 years lifetime, and replaceable
n Power and Battery:
Using 2 CR2032 button cells for the power, save energy and freely to load.
n Battery/cell lifetime : 6—8 months in the state of open mode.
n LCD Display: show the power situation and co concentration value
n LED light: blue power indicator and red alarm light
n Buzzer: sound alarm. 75dB/1m
n Other parameter:
u static current: < 90uA alarm current: < 25mA
u Working state: temperature: 4℃-38℃, humidity: 25%--85%
n Appearance Size : 66.8*46.8*14.8 mm
n Weight : 50.8g (with battery); 45g (without battery)
n Packing list:
n Suggestion for the using place:
Can be hang on the car rearview mirror or fixed to other places which is out of driver’s slight.
The treatment and attention after alarm is making
Alarm concentration reference
Concentration (ppm) | Alarm |
50--79 | 90mins 1 level alarm |
80--99 | 60mins 2 level alarm |
100--149 | 40mins 3 level alarm |
150--199 | 30mins 4 level alarm |
200-249 | 10mins 5 level alarm |
250--299 | 6mins 6 level alarm |
300---349 | 3mins 7 level alarm |
350--399 | 90s 8 level alarm |
Above 400 | 9 level alarm at once |
Using tips:
n This device’s accuracy will be influenced by itself body, installation environment’s temperature, humidity and other factors. So the best installation environment is:
n temperature: 20°C±5°C;
n humidity: 50%, don’t put in the air of the humidity is over 80%
n far away from the places where it has phone and other electromagnetic interference;
n Keep it away from the corrosive or harmful substances;
n Don’t put it in high co concentration environment in order to save its lifetime.
Company Profile
Beijing Dashiweiye Tech Co., Ltd., a famous product designing center and manufacturing company for plastic parts, is mainly engaged in product design, plastic mold making and plastic enclosures manufacturing.
Setting foot on Beijing, our company is a technology innovation enterprise specialized in the R&D, manufacture, marketing gas-detection products.
Our main products cover the industrial toxic gas detector, oxygen content detector, explosive gas detecting alarm ,environmental monitoring ,home gas detection and other fields, they are widely used in industrial and civilian various occasions. In the fields of industrial ,metallurgy ,coal mine ,petroleum chemical ,environmental protection ,municipal services and so on, many products are used in the badness environment for a long time and they shown excellent technical quality so that our company gets a good reputation and extensive visibility.
People-oriented and science and technology development is ours concept, we not only has mature products of many areas for users to choose, but also we can provide the product's design according to customers' special requirement. We can provide the complete new project for the appearance, structure and the PCB, and we provide new products with independent knowledge property rights!
Great efforts are made to combine apparent and structure designs of the products. Designers and engineers allow our company to have achievable product design solutions and products with outstanding cost-performance ratio.
We are committed to the design and development of plastic shells and PCBs of industrial products like instruments and meters. Our business covers industrial products for electricity, central air-conditioning system, thunder prevention, coal mine, bank, postal and telecommunication service, railway, medical care, security & protection and prospecting, centering on providing service to brand enterprises in different product fields.
We try everything we can to provide our clients with industrial designs and professional services that take lead in the trend of market consumption, and rely on it to form a long-term and stable cooperation with clients.
