single side aluminum infrared led tube light pcb smd board
NO |
ITEM |
Technical capabilities |
1 |
Layer |
2-20layers |
2 |
Max. Board size |
2000×610mm |
|
3 |
Min. board Thickness |
2layer 0.15mm 4layer 0.38mm 6layer 0.55mm 8layer 0.80mm 10layer 1.00mm
|
4 |
Min.line Width/Space |
0.075mm(3mil) |
5 |
Max. Copper thickness |
6OZ |
6 |
Min. S/M Pitch |
0.075mm(3mil) |
7 |
Min. hole size |
0.1mm(4mil) |
8 |
Hole dia. Tolerance (PTH) |
±0.05mm(2mil) |
9 |
Hole dia.Tolerance (NPTH) |
+0/-0.05mm(2mil) |
10 |
Hole position deviation |
±0.05mm(2mil) |
11 |
Outline tolerance |
±0.10mm(4mil) |
12 |
Twist & Bent |
0.75% |
13 |
Materials |
FR4,H-TG,Teflon,Rogers,Ceramics,Aluminium
|
14 |
Electric strength |
>1.3kv/mm |
15 |
S/M abrasion |
>6H |
16 |
Thermal stress |
288℃ 20Sec |
17 |
Test Voltage |
50-300V |
18 |
Min. blind/buried via |
0.15mm (6mil) |
19 |
Surface Finished |
HASL, ENIG, ImAg, Imsn OSP, Plating AG, Plating gold |
single side aluminum infrared led tube light pcb smd board
single side aluminum infrared led tube light pcb smd board
We specialized in:
l PCB design, PCB layout, PCB manufacturing, PCB Assemblies,
l One-stop services from PCB to PCB assembly
l components sourcing, PCBA Function Test, design solution.
l Electronic testing circuit board or PCBA
l Eleectronic manufacturing service
Packing |
Inner packing: Vacuum packing / Plastic bag Outer packing: Standard carton packing |
Payment terms |
L/C,T/T, Western Union,Paypal |
Trade terms |
FOB,CIF,DDP |
FOB port |
Shenzhen, Hongkong |
Why choose us?
1. Your inquiry related to our products or prices will be replied in 24hrs.
2. Well-trained and experienced staffs to answer all your enquires in fluently English
3. OEM&ODM, we can help you to design and put into product.
4. Distributorship are offered for your unique design and some our current models
5. Protection of your sales area, ideas of design and all your private information
1.Which type of PCBs do you expert in?
We are specialized in producing Single
side PCB,Doubleside PCB, Multilayer PCB,Aluminium PCB,Spray Tin PCB,Immersed Gold PCB,
etc.
2.What is your Lead time?
Lead time is usually punctual here, usually 5-10 days for PCB sample, 10-15 days for mass production. For some special situation, we can also advise customer in advance to avoid any inexpectation or loss at customer side.
3.What is your testing policy and how you controle the quality?
For sample, usually tested by flying probe; for PCB Volume over 3 square meters, usually tested by
fixture, this will be more faster. Due to there’s many steps to PCB production, we usually do inspection after every step.
4.What is your package?
With Inner vacuum package and out carton.
5.Will you allow me to put several part number together into one panel?
Yes, this is usually happen in we factory, this way can help customers reduce some cost and to
a certain degree, it can help reduce some assembly cost.
6.What is your minimum order quantity?
We have no limitation on MOQ, prototype, medium volume and large volume are all acceptable.
7.Are my design files safe when I submit them to you for manufacturing?
Any customer’s file will be protected very well here in our factory and we will not let any third party
know. We can sign NDA with you.
1.Waterproof SMD Rigid and flexible led strip lights with different length available
2.wide lighting angle and different colors of single colors and RGB color.
3.OEM/ODM are welcomed
4.Print your Logo on PCB board are available
How to work with us
Sograce International Corporation Limited is a professional PCB manufacturer for producing all kinds of single side, doubleside and multilayer pcb, also provide assembly service with 10 years experience.We have a variety of advanced production equipments, excellent engineering and technical personnels, accompany with the mature management and service system.Our pcbs meet IEC,IPC,DIN,MIN standard, behaves ISO9001 quality system ,UL and Rohs certificate. Fast lead time and competitive price with high quality are our advantages. PCB lead time is within 10days,and most can be within 7days. We also established a prototype team to develop customer’s prototype needs. prototype lead time often can be within 3days.
single side aluminum infrared led tube light pcb smd board
Choose Sograce, Choose the best partner!
Skype ID: sograce-sales11
What's App: +8613715320875
welcome for your inquiry!
