We specialize in:
l LED circuit design, led PCB manufacturing,LED SMT Assembly,
l One-stop services from PCB to PCB assembly
l Components sourcing, LED products Test, design solution.
l Electronic testing circuit board or PCBA
l Eleectronic manufacturing service
NO |
ITEM |
Our PCB Technical capabilities |
1 |
Layers |
2-20 layers |
2 |
Max. Board size |
2000×610mm |
3 |
Min. board Thickness |
2-layer 0.15mm |
4-layer 0.38mm | ||
6-layer 0.55mm | ||
8-layer 0.80mm | ||
10-layer 1.0mm | ||
4 |
Min. line Width/Space |
0.075mm(3mil) |
5 |
Max. Copper thickness |
6OZ |
6 |
Min. S/M Pitch |
0.075mm(3mil) |
7 |
Min. hole size |
0.1mm(4mil) |
8 |
Hole dia. Tolerance (PTH) |
±0.05mm(2mil) |
9 |
Hole dia. Tolerance (NPTH) |
+0/-0.05mm(2mil) |
10 |
Hole position deviation |
±0.05mm(2mil) |
11 |
Outline tolerance |
±0.10mm(4mil) |
12 |
Twist & Bent |
0.75% |
13 |
Insulation Resistance |
>1012 Ω Normal |
14 |
Electric strength |
>1.3kv/mm |
15 |
S/M abrasion |
>6H |
16 |
Thermal stress |
288°C 20Sec |
17 |
Test Voltage |
50-300V |
18 |
Min. blind/buried via |
0.15mm (6mil) |
19 |
Surface Finished |
HAL, ENIG, ImAg, Imsn OSP, Plating AG, Plating gold |
20 |
Materials |
FR4,H-TG,Teflon,Rogers,Ceramics,Aluminium, Copper base |
Quote requirement for pcb and pcb assembly:
1.Circuit board assembly fabrication:
Onestop pcb assemblies service, PCB design, PCB layout, PCB manufacturing,
PCB Assemblies, components sourcing, PCBA Function Test, design solution.
2.Quote Needed:
1.PCB Gerber File;
2.Bom List for PCB Assembly;
3. Send us a sample of PCBA to make the exactly same for you.
4. Test Method for PCB Assembly.
3.PCB+COMPONENTS+SMT the whole service with top quality and very competitive price for you;
OEM design and custom made products are welcomed.
Our Certifications:
Packaging & Delivery
|
Packaging Details:
|
The electronic PCBA PCB assembly, PCB PCBA,PCB design in Sograce is:
|
|
Delivery Detail:
|
3-5 working days for sample,7-10 working days for mass order
|
1.Which type of PCBs do you expert in?
We are specialized in producing Singe-side PCB,Double-side PCB, Multilayer PCB,Aluminium PCB,Spray Tin PCB,Immersed Gold PCB, etc.
2.What is your Lead time?
usually 3-7 days for PCBA sample, 5-10 days for mass production.
3.What is your testing policy and how you controle the quality?
For sample, usually tested by flying probe; for PCB Volume over 3 square meters, usually tested by fixture, this will be more faster. Due to there’s many steps to PCB production, we usually do inspection after every step.
4.What is your package?
With Inner vacuum package and out carton.
5.Will you allow me to put several part number together into one panel?
Yes, this is usually happen in we factory, this way can help customers reduce some cost and to a certain degree, it can help reduce some assembly cost.
6.What is your minimum order quantity?
We have no limitation on MOQ, prototype, medium volume and large volume are all acceptable.
Sograce International Corporation Limited
is a professional PCB manufacturer for poducing all kinds of single side, double-side and multilayer pcb,
also provide assembly service with 10 years experience.We have a variety of advanced production equipments,
excellent engineering and technical personnels, accompany with the mature management and service system.
Our pcbs meet IEC,IPC,DIN,MIN standard, behaves ISO-9001 quality system ,UL and Rohs certificate.
Fast lead time and competitive price with high quality are our advantages. PCB lead time is within 10days,
and most can be within 7days. We also established a prototype team to develop customer’s prototype needs.
prototype lead time often can be within 3days.
More information about PCB, pls contact with us!
Skype ID: sograce-sales07
