Base Material Aluminum Base, Aluminium
Copper Thickness 1oz, 2OZ
Board Thickness 1.6mm, 1.5mm
Min. Hole Size 0.20mm, 0.1mm
Min. Line Width 0.075mm/0.1mm(3mil/4mil), 0.075mm
Min. Line Spacing 0.075mm 0.1mm(4mil) 0.2mm, 0.075mm
Surface Finishing ENIG HASL OSP, HASL, ENIG, ImAg, Imsn OSP, Plating AG, Plating gold



Specifications:

1.Power Alumium LED Round PCB
2.UL ROHS ISOCertificate100%E-tested
3.Survice by quality Win by price
4.Delivery5~7days



Product Description



Aluminium pcb for led lamp,china aluminium pcb,led alumium pcb board

Aluminum PCB is one of metalbased pcb,including copper foil,thermal insulating layer and metal substrate,its structure divide into three layers:
1. Circuit layer: the equivalent of an ordinary PCB,copper thickness from 1oz to 10oz.
2. Insulation layer: Insulation is a layer of thermal insulating material with low thermal resistance.

    Thickness: 0.003 "to 0.006" inch is the aluminum pcb core technology.
3. Based Layer: a metal substrate,usually aluminum or copper may be chosen.



Peculiarity of Aluminum PCB:

High Heat dissipation, Electromagnetic Shielding, High Mechanical Strength, Excellent processing performance.

Application: Products are applied to a wide range of Hightech industries such as:telecommunication, computer application,Medical devices,lighting, game machine,  industrial control, power, automobile and high-end consumer electronics, ect.





 Specifications of led alumium pcb board:



Product Type

Al Clad PCB 1 layer~2 layer

Maximum Panel size

20"*24" (1170mm*600mm)

Copper thickness

0.5oz, 1oz, 2oz, 3oz and 4 oz

Dielectric Thickness
(to Substrate)

0.05mm, 0.075mm, 0.1mm,0.15mm,0.2mm

Substrate Core Thickness

0.4mm,0.6mm, 0.8mm, 1.0mm, 1.2mm, 1.5mm,2.0mm, 3.0mm and 3.2mm

Finished Board Thickness

0.4mm To 4.0mm

Thickness Tolerance

+/-10%

Aluminum Machining

Drilling,Tapping,Milling,Routing, Die-Punching,break-off tab available

Min. Finish hole size

0.25mm

ing voltage

2.5kVDC(0.075mm Dielectric), 3.75kVDC (0.15mm Dielectric)

Min.Track Width

0.2mm (8mils)

Min.Track gap

0.2mm (8mils)

Min. SMD pad pitch

0.2mm (8mils)

Surface Finishing

HASL, HASL Leadfree, Immersion gold, Flash gold, OSP

Soldermask color

White, Black, others Available

Legend color

Black, White, others Available

Etest

YES

Rohs

YES

Reference Standard

IPC-A-600G Class 2

Special holes

Spot facing, Cup holes

Data Input

Gerbers, AutoCad, Cam350, PROTEL 99SE,PROTEL DXP,
POWER PCB,ODB+.(TGZ)







Quotation time:



1. For PCB & FPC: quotation within 1 hours if all information are clear
2. For PCBA: quotation within 2 days if all information are clear







Quote Requirements For PCB and PCB Assembly :



- Gerber File and Bom List;
- Quote Quantity;
- Technical requirements for quoting reference;
- Clear pictures of PCB or PCB Assembly sample if available.
- Inspection method for PCB Assembly.





Lead Time For Production Orders:





    Sample Lead time(days)

 Mass production lead time(days)

Single sided PCB

1~3

4~7

Double sided PCB

2~5

7~10

Multilayer PCB

7~8

10~15

PCB and Assembly

8~15

15~30
