p10 single color LED module LED Display Advertising Light display screen
USD $5 - $7
/ Piece
5 Pieces(Min.Order)
- 2000000 Piece / Pieces per Month
- Shenzhen
- Credit Card PayPal
You May Like
-
60W UL CE LED Canopy Lamp with aluminum frame Ex-factory price from Shenzhen
-
80W Energy-Saving Gas Station LED Canopy Lamp hot sale from Shenzhen
-
60W UL CE Energy Saving LED Canopy Lamp with 3 years warranty from Shenzhen
-
2014 new design, led flood light, led Gas Station Lamp, LED canopy light 100w
-
Led flood light, led Gas Station Lamp, LED canopy light 100w
-
120W High power cree led canopy lamp Wholesale from Shenzhen for gas staton
Product Details
| Place of Origin: | Guangdong, China | Brand Name: | Helilai | Model Number: | Helilai-P10-Red |
| Usage: | Outdoor | Tube Chip Color: | Red | Display Function: | Graphics |
| Pixels: | 10mm | Screen Dimension: | 320mmx160mm |
Product Description
Parameter
| The technology paramete p10 mm | ||
| Number | Item | P10 |
| 1 | Pixel pitch | 10mm |
| 2 | Size of module | 320mmX160 mm |
| 3 | Resolution of module | 32 X16 |
| 4 | Density of pixel | 10000dots/m2 |
| 5 | Pixel configuration | R or G or B or |
| 6 | Red wavelength | 625± 2nm |
| 7 | Green wavelength | 525± 2nm |
| 8 | Blue wavelength | 470± 2nm |
| 9 | Colors | 16777216 |
| 10 | Best viewing distance | 10-150m |
| 11 | Horizontal viewing angle | 120° |
| 12 | power consumption | 200w/m2 |
| 13 | Brightness | > 2000cd /m2 |
| 14 | Gray scale | 16bits per color |
| 15 | Color temperature | 6500k |
| 16 | Control method | Synchronization & Asynchronization |
| 17 | Driving method | constant scanning |
| 18 | Frame frequency | 60Hz |
| 19 | Refresh frequency | > 300Hz |
| 20 | Working voltage | AC220V/110V± 10% |
| 21 | IP grade | IP67 |
| 22 | Working temperature | -20° C~80° C |
| 23 | MTBF | > 10000 hours |
| 24 | Life span | > 100, 000 hours |
| 25 | Defects rate. | ≤ 0.00001(Led display line standard< 0.0001) |
Advantage
We can offer you a very cheap price with top quality modules!
Contact me to get the cheap price and catalogue!
Angel Lee (Sales Manager)
Mob: +86 13266771147
Skype : jackybrazil
Wechat : wxid_jpfqwnv991eu21
QQ :1158665386
Tel : +86 755 33560649
FAX : +86-755-89474486-603
FAX : +86-755-89474486-603
