8CBM Asphalt Tank Asphalt Synchronous Chip Sealer
US$ 180,000 - 200,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
Yihong
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
14m3 Sino Truck Asphalt Synchronous Chip SealerUS$ 180,000 - 200,000MOQ: 1 Set -
YH5314TFC Asphalt Synchronous Chip SealerUS$ 180,000 - 200,000MOQ: 1 Set
-
8CBM Asphalt Tank Asphalt Chip SealerUS$ 180,000 - 200,000MOQ: 1 Set
-
14m3 Sino Truck Asphalt Chip SealerUS$ 180,000 - 200,000MOQ: 1 Set
-
14m3 Sino Truck Chip Sealer PaverUS$ 180,000 - 200,000MOQ: 1 Set
Condition
New
Place of Origin
Henan, China
Brand Name
Yihong
Model Number
YH5314TFC
Dimension(L*W*H)
11990 x 2500 x 3860mm
Weight
31000kg
Power(W)
276KW
Certification
3C,CE,ISO9001,SGS
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
8CBM asphalt tank asphalt synchronous chip sealer overview
The 8CBM asphalt tank asphalt synchronous chip sealer is used for chip sealing the surfaces of roads and coating and waterproofing bridges. Asphalt binder spraying and aggregate spreading are performed synchronously so they achieve maximum cohesion.
The asphalt sealer is researched and developed independently, earning proprietary intellectual property rights for its advanced technology. Improving the design, we have enlarged the asphalt tank to 8 m³. This 8CBM asphalt tank asphalt synchronous chip sealer can spread chips without lifting the hopper, which allows it to be used in narrow spaces, such as under bridges or around curves. A strong agitator in the asphalt tank prevents the asphalt rubber from separating into liquids and solids and solids. The pavement chip sealer incorporates mechanical, electric and hydraulic systems in one machine, simplifying the operating process.
8CBM asphalt tank asphalt synchronous chip sealer for sale features
1. The 8CBM asphalt tank asphalt synchronous chip sealer reduces the intensity of labor intensity, initial budget, and human resources while improving work efficiency and quality.
2. The road maintenance equipment derives force from the tractor so it runs stably and sprays evenly.
3. Features good insulation, temperature drops that are ≤2℃/h(15℃), corrosion-resistance and durability.
4. High precision nozzles ensure spraying consistency.
5. Remote control features make the chip sealing equipment easy and convenient to operate 8CBM asphalt tank asphalt synchronous chip sealer technical paramenter
Product Model | YH5314TFC |
Chassis Model | ZZ3317N4667D1 |
Spray Width | 3800mm |
Spray Volume | 0.2-3.0kg/m3 |
Aggregates Size | 3-25mm |
Asphalt Tank | 8m3 |
Aggregate Hopper | 14m3 |
Heater | Imported Diesel Heater(2x10x104kCal/h) |
Spray Medium | Hot(modified)Asphalt, Cutback, Emulsion Asphalt Rubber |
Gross Vehicle Weight | 31000kg |
Dimension | 11990x2500x3860 |
8CBM asphalt tank asphalt synchronous chip sealer key components
| NO | NAME | BRAND | QTY | PLACE OF ORIGIN |
| 1 | Asphalt pump | Johnson | 1 | Belgimu |
| 2 | Heat oil pump | Johnson | 1 | Belgium |
| 3 | Transfer case | Yijie | 1 | China |
| 4 | Encoder | Koyo | 1 | Japan |
| 5 | Burner | Beckett | 2 | America |
| 6 | Vechicle dedicated controller | Yingzhijie | 3 | China |
| 7 | Velocity radar | Dickey-john | 1 | American |
| 8 | Tough screen | Xinjie | 1 | China |
| 9 | HD camera | Aokaipu | 2 | China |
| 10 | Servo pump | Sauer-Danfoss | 1 | American |
| 11 | Lifting hydraulic cylinder | Haizhanli | 1 | China |
| 12 | Gear motor | TJ | 1 | China |
| 13 | Cycloid motor | Eaton | 1 | America |
| 14 | Cycloid motor | Sauer-Danfoss | 1 | America |
| 15 | Radia piston motor | Seat | 1 | Italy |
| 16 | Hyduaulic cylinder | Steady | 1 | China |
| 17 | Integrated control valve | Hydra Force | 2 | America |
| 18 | One-way throttle valve | Tognella | 4 | Italy |
| 19 | Radiator | AKG | 1 | Germany |
| 20 | Double directional hydraulic lock | Tognella | 2 | Italy |
8CBM asphalt tank asphalt synchronous chip sealerworkshop
