Mini Cheap Mig Welder IGBT Inverter Mig160 Welding Machine
US$ 60 - 100
MOQ: 15 Pieces
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Guangdong, China
Brand Name:
WM Mig welder
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
MIG160 Inverter Welding Machine Mig/tig WelderUS$ 80 - 200MOQ: 30 Sets -
MAG MIG160 Inverter Mig Tig Mma Welding MachineUS$ 80 - 200MOQ: 30 Sets
-
160AMP Igbt Inverter Mig Welding WireUS$ 80 - 200MOQ: 30 Sets
-
Pulse Frequency Inverter for TIG200pacdcUS$ 60 - 100MOQ: 15 Pieces
-
dc ac Inverter With High FrequencyUS$ 60 - 100MOQ: 15 Pieces
Condition
New
Place of Origin
Guangdong, China
Brand Name
WM Mig welder
Model Number
MIG160
Wire Feeding Speed
1.5-16mm
Dimensions
480*230*360mm
Weight
18kg
Usage
manufacturing of hardware,decorations,pipeline install,metalplates
Voltage
230v
Power(W)
5.8kva
Certification
CE and Rohs
Warranty
2 years
Specifications: mini cheap mig welder IGBT inverter mig160 welding machine
| Input Voltage(V) | AC230V±15%(singlephases) 50/60Hz |
| Input voltage current(A) | 25 |
| Power capacitance(KVA) | 5.8 |
| Recommended fuse capacity(A) | 50 |
| Current adjustment range(A)(MMA) | 10~160 |
| Current adjustment range(A) | 30~160 |
| Voltage adjustment range(V) | 11~22 |
| No-load voltage(V) | 51 |
| Wile feeding speed range(m/min) | 1.5~1.6 |
| Welding wire diameter(mm) | 0.6/0.8/0.9 |
| Duty cycle imax(40℃) | 120A/35% |
| Duty cycle 100%(40℃) | 100A |
| Efficiency(%) | 85 |
| Power factor | 0.72 |
| Insulation class | F |
| Protection Class | IP21S |
| Size (mm) | 480*230*360 |
| Weight(KG) | 18 |
Features
·MIG/TIG/MMA multi-function IGBT inverter
·Fit for wire diameter 0.6—1.0mm
·Optional ABS face and rear for innovative design
·This inverter’s stable arc is suitable for almost any welding need
Accessories
Standard:
·1pc of 3m MB15 MIG torch, 1 set of 300A Earth clamp +3m 16mm² Cable +KDP -16A,
1pc KDP-16A for MIG160/160III
Optional:
·MIG Package1:1 set of 200A Electrode holder +3m 16mm² Cable+KDP-16A For MIG160/160III
Specifications
Standard:
·MIG/MAG
Voltage knnb
Wire feeding speed knob
Burn back (1-5S)
·MMA
Current knob
·Gasless FCAW
·O.H. alarm indicator
·Power indicator
·Inching wire feed button
Optional:
·1PCB MIGA160 machine
·Dual voltage 115/220V MIG160
·Double drive wire feeder
