Help CenterElectric Power Inverter for Cutting Machine
Related Products
-
Welding Electric Hand Tools With ac dcUS$ 60 - 100MOQ: 15 Pieces -
220v Inverter for Single PhaseUS$ 60 - 100MOQ: 15 Pieces
-
TIG200 ac dc Inverter With PulseUS$ 60 - 100MOQ: 10 Pieces
-
2015 High Quality Inverter Mini MIG WeldingUS$ 80 - 200MOQ: 30 Sets
-
Three Phase Inverter Pcb Board With Arc220US$ 60 - 100MOQ: 15 Pieces
Spefication: MOSFET high frequency welding and cutting machine
Rated Input Voltage(V) |
AC 230V±15%(single phases) 50/60HZ |
Rated Input Current(A) |
19 |
Rated Input Capacity(KVA) |
4.2 |
No-load Voltage(V) |
40 |
Efficiency(%) |
85 |
Power Factor |
0.93 |
Protection Class |
IP23 |
Insulation Class |
B |
Size (mm) |
371*155*285 |
Weight(KG) |
9 |
|
TIG |
MMA |
PLASMA |
Input current(A) |
10.2 |
15.6 |
19. |
Output current(A) |
120 |
110 |
30 |
Current range(A) |
10~120 |
10~110 |
15~30 |
N0-load voltage(V) |
55 |
55 |
220 |
Working voltage(V) |
15 |
25 |
92 |
Duty cycle imax(25℃) |
60% |
60% |
60% |
Duty cycle 100% (25℃) |
90A |
85A |
20A |
Nozzle intermal(mm) |
|
|
1.0 |
Air pressure(Mpa) |
|
|
0.4 |
Gas flow(L/h) |
120~300 |
|
7800 |
Max,cutting thickness(mm) |
|
|
8 |
Quality cutting thickness(mm) |
|
|
5 |
Arc starting |
HF vibration |
Touch |
HF vibration |
Features
·Plasma cutting, TIG MMA functions included
·HF touch arc starting,economical and practical
·Compact,light and portable
Standard
·1pc of 4m SR-17 TIG torch, 1pc of 5m PT-31 plasma torch,1set of 300A Earth clamp+3m*10mm² Cable +KDP16A,1pc KDP-16A,1set of air regulator,1pc 1.6*150mm tungsten electrode for CT312
Optional:
·CT Pakage1:1 set of 300A Electrode holder +3m 16mm² Cable
·Custom-designed luxury case
Specifications
Standard
·Plasma cutting
·O.C&O.H alarm indicator
·Digital display
·TIG
·MMA
·Current knob
·O.C indicator (O.C&O.H alarm)
·Power supply indicator
