Specification: Module inverter circuit diagram
| Input Voltage(V) | AC230V±15%(singlephases) 50/60Hz |
| Input voltage current | 47 |
| Power capacitance(KVA) | 10.8 |
| MMA welding current range(A) | 10~250 |
| MIG current range(A) | 25~250 |
| MIG voltage range(V) | 11~29 |
| Duty cycle imax(40℃) | 250A/35% |
| Duty cycle 100%(40℃) | 148A |
| Electrod diameter applicable(mm) | 0.6/0.8/0.9/1.0 |
| Efficiency(%) | 85 |
| Power factor | 0.72 |
| Insulation class | F |
| Protection Class | IP21S |
| Size (mm) | 880*296*616 |
| Weight(KG) | 45 |
welding machine,welding machine, welding machine, welding machine, welding machine, welding machine
Features
·Triple function machine covering MIG welding, MMA welding and gasless –FCAW welding
·High duty cycle ensures high performance welding over longer durations
·Our advanced control circuitry increases the MIG welding function
·Stable welding arc,minimal spatter &beautiful shaping
·High welding efficiency
Accessories
Standard:
·1pc of 3m MB24MIG torch, 1 set of 300A Earth clamp +3m 25mm² Cable +KDP -70A,
1pc gas regulator for MIG 250(N292)
Optional:
·MIG Package2:1 set of 300A Electrode holder +3m 25mm² Cable+KDP-70a For MIG250(N292)
Specifications
Standard:
·MIG
Voltage knnb
Wire feeding speed knob
Burn back
·MMA
Current knob
·Gasless FCAW
·Spol gun interface
·Digital display A/V
·Alarm indicator O.C/O.H
·Power indicator
·Inching wire feed button
·Trolley
Optional:
·3ph 380V
·Lift-arc/TIG
·2T/4T funcation
·V.R.D
