Industrial Label Printer Godex ZX1300 300DPI
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Other, label printer
Style:
Black And White
Payment & Shipping
Payment Methods:
Port of Shipment:
EXW Warsaw
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Thermal Transfer Barcode Printer RT200 (USB, RS232, Ethernet), 200dpiNegotiableMOQ: 1 Unit -
Thermal Transfer Barcode Printer G300 (USB, RS232, Ethernet), 203dpi, 4"NegotiableMOQ: 1 Unit
-
Thermal Transfer Barcode Printer RT200i (USB, RS232, Ethernet), LCD, 203dpiNegotiableMOQ: 1 Unit
-
Thermal Transfer Barcode Printer RT230 (USB, RS232, Ethernet) 300dpiNegotiableMOQ: 1 Unit
-
Thermal Transfer Barcode Printer RT230i (USB, RS232, Ethernet), LCD, 300dpiNegotiableMOQ: 1 Unit
Products Status
Stock
Type
Other, label printer
Style
Black And White
Use
Barcode Printer
Interface Type
Other, USB 2.0 (B); RS-232 (DB-9); IEEE 802.3 10/100; 3 USB Host (A)
Max Paper Size
118mm
Black Print Speed
Up to 7 IPS (177 mm/s)
Color Print Speed
n/a
Max. Resolution
300 dpi
Brand Name
Godex
Model Number
ZX1000
Place of Origin
Taiwan, China
Our next generation, high output industrial barcode printer.Various standard interfaces facilitate integration into several environments. Compact and robust steel design will fulfill yor most demanding applications.
Features:
Large intuitive touch screen LCD allows the user to be in control.
Three USB host ports standard allows integration with several devices.
High performance printer designed for high volume applications in mind
Up to 10 ips print speed
New hardware ideal for both high volume or precision printing applications
Optional Ribbon Rewind Module allows easy and fast ribbon replacement.
300 DPI model
| Print Method | Thermal Transfer / Direct Thermal |
| Resolution | 300 dpi (12 dots/mm) |
| Print Speed | Up to 7 IPS (177 mm/s) |
| Print Width | 4.09” (104 mm) Up to (105.7mm) |
| Print Length | Min. 0.16” (4 mm)** – Max. 85” (2159 mm) |
| Processor | 32-bit MPU |
| Memory | Flash 128 MB Flash (60 MB for user storage) SDRAM 32 MB |
| Sensor Type | Adjustable reflective sensor and transmissive sensor, left aligned |
| Media | Type:Continuous form, gap labels, black mark sensing, and punched hole; label length set by auto sensing or programming Width : Tear : Min. 1” (25.4 mm) – Max. 4.64” (118 mm) Cutter : Max. 4.61” (117 mm) Dispenser / Rewind : Max. 4.64” (118 mm) Thickness:Min. 0.003” (0.06 mm) – Max. 0.01” (0.25 mm) Label roll diameter:Max. 8” (203.2 mm) Core diameter:Min. 1.5" (38.1 mm) – Max. 3" (76.2 mm) |
| Ribbon | Types:Wax, wax/resin, resin Length:Max. 1476’ (450 m) Width :Min. 1.18” (30 mm) – Max. 4.33” (110 mm) Ribbon roll diameter:3” (76.2 mm) Core diameter:1” (25.4 mm) |
| Printer Language | EZPL, GEPL, GZPL auto switch |
| Software | Label design software: GoLabel (for EZPL only) Driver:Windows XP, Vista, Win7, Win8, Server 2003 & 2008 DLL: Windows XP, Vista, Win7, Server 2003 & 2008 |
| Resident Fonts | Bitmap Fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A&B Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable Bitmap fonts 8 times expandable in horizontal and vertical directions Scalable Fonts: 90°, 180°, 270° rotatable |
| Download Fonts | Bitmap Fonts: Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable Asian Fonts : Asian fonts 90°, 180°, 270° rotatable and 8 times expandable in horizontal and vertical directions Scalable Fonts: Scalable fonts 90°, 180°, 270° rotatable |
| Barcodes | 1-D Bar Codes: Code 39, Code 93, EAN 8 / 13 (add on 2 & 5), UPC A / E (add on 2 & 5), I 2 of 5 & I 2 of 5 with Shipping Bearer Bars, Codabar, Code 128 (Subset A, B, C), EAN 128, RPS 128, UCC 128, UCC / EAN-128 K-Mart, Random Weight, Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM, GS1 DataBar 2-D Bar Codes: PDF417, Micro PDF417, Datamatrix code, Maxicode, QR code, Micro QR code and Aztec code |
| Code Pages | Codepage 437, 850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866, 869, 737 Windows 1250, 1251, 1252, 1253, 1254, 1255, 1257 Unicode (UTF8,UTF16) |
| Graphics | Resident graphic file types are BMP and PCX, other graphic formats are downloadable from the software |
| Interfaces | • USB 2.0 (B-Type) • Serial port: RS-232 (DB-9) • IEEE 802.3 10/100 Base-Tx Ethernet port (RJ-45) • 3 USB Host (A-Type). 2 ports at the front panel, 1 port at the rear panel |
| Control Panel | • Backlight 3.2” touch screen LCD • 1 Power on/off button with green color LED backlight • 1 Control key : FEED / PAUSE / CANCEL with dual color LED backlight: Ready (Green); Error (Red) • 1 Calibration button at rear panel |
| Power | Auto Switching 100-240V AC, 50-60Hz |
| Real Time Clock | Standard |
| Environment | Operation temperature: 41°F to 104°F (5°C to 40°C) Storage temperature: -4°F to 140°F (-20°C to 60°C) |
| Humidity | Operation: 20-85%, non-condensing Storage: 10-90%, non-condensing |
| Agency Approvals | CE (EMC),FCC Class A,CB,cUL,CCC,KC |
| Dimension | Length: 18.30” (465 mm) Height: 10.35” (263 mm) Width : 12” (305 mm) |
| Weight | 30 lbs (13.6 Kg), excluding consumables |
| Options | Cutter module (User install) Parallel port adaptor module (Centronic female 36-pin) Bluetooth module WiFi print server module (IEEE 802.11b/g/n) Applicator Interface (DSUB female 15-pin) External label roll holder for 10” (250 mm) O.D. label rolls External label rewinder Label Dispenser + Internal Rewinder (factory install) RFID R/W module (project option) |
