Thermal Transfer Barcode Printer G300 (USB, RS232, Ethernet), 203dpi, 4"

Thermal Transfer Barcode Printer G300 (USB, RS232, Ethernet), 203dpi, 4" thumbnail-1
Thermal Transfer Barcode Printer G300 (USB, RS232, Ethernet), 203dpi, 4" photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Other, Printer Thermal Transfer
Style:
Black And White
Contact Supplier Request Quote Chat Now
Compart International M.M. Kaluzni Sp. J.
Payment & Shipping
Payment Methods:
Port of Shipment:
EXW Warsaw
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Type Other, Printer Thermal Transfer
Style Black And White
Use Barcode Printer
Interface Type Other, Serial port: RS-232 (DB-9), USB port, Ethernet 10/100Mbps
Max Paper Size 118
Black Print Speed 102mm/s
Color Print Speed n/a
Max. Resolution 203dpi
Brand Name Godex
Model Number G300
Place of Origin Taiwan, China
4" barcode printer (thermal transfer), easy paper loading, print width 108mm, 203 dpi, fast printing speed (max. 102mm/s), USB, RS-232, Ethernet (LAN); free GoLabel label design software


Economical 4” Thermal Transfer Desktop Printer. Use the G300 for all you light to medium duty thermal transfer barcode printing applications.

- Ethernet, Serial and USB ports included
- Uses standard low-cost labels and ribbons
- High cost-effectiveness for large amount printing
- Free labeling software GoLabel / QLabel for easy printing
- 203 DPI model

Print Method: Thermal Transfer / Direct Thermal
Resolution: 203 dpi (8 dots/mm)
Print Speed: 4 IPS (102 mm/s)
Print Width: 4.25" (108mm)
Print Length: Min. 0.16” (4 mm); Max. 68” (1727 mm)
Memory: 8MB Flash (4MB for user storage) / 16MB SDRAM
Sensor Type: Fixed transmissive sensor and Fixed reflective sensor

Media
Types: Continuous form, gap labels, black mark sensing, and punched hole; label length set by auto sensing or programming
Width: 1” (25.4 mm) Min. - 4.64” (118 mm) Max.
Thickness: 0.003” (0.06 mm) Min. - 0.008” (0.20 mm) Max.
Label roll diameter: Max. 5” (127 mm)
Core diameter: 1”, 1.5” (25,4 mm, 38,1 mm)

Ribbon: Types: Wax, wax/resin, resin; Length: 360’ (110 m); Width: 1.18” Min - 4.33” (30 mm - 110 mm) Max; Ribbon roll diameter.: 1.57“ (40 mm); Core diameter: 0.5” (12.7 mm)
Printer Language: EZPL, GEPL, GZPL auto switch
Software: Label design software: QLabel-IV, GoLabel (for EZPL only)
Driver & DLL: Windows 2000, XP, Vista, 7, Windows Server 2003 & 2008

Resident Fonts:
Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable
Bitmap fonts 8 times expandable in horizontal and vertical directions
Scalable fonts 90°, 180°, 270° rotatable

Download Fonts:
Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable
Asian fonts 90°, 180°, 270° rotatable and 8 times expandable in horizontal and vertical directions
Scalable fonts 90°, 180°, 270° rotatable

Barcodes: 1-D Bar codes: Code 39, Code 93, EAN 8 /13 (add on 2 & 5), UPC A/E (add on 2 & 5), I 2 of 5 & I 2 of 5 with Shipping Bearer Bars, Codabar, Code 128 (subset A, B, C), EAN 128, RPS 128, UCC 128, UCC/EAN-128 K-Mart, Random Weight, Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM, and GS1 DataBar
2-D Bar codes: PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code and Aztec code
Code Pages: CODEPAGE 437, 850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866, 869, 737; WINDOWS 1250, 1251, 1252, 1253, 1254, 1255,1257; Unicode (UTF8, UTF16)
Graphics: Resident graphic file types are BMP and PCX, other graphic formats are downloadable from the software
Interfaces: Serial port: RS-232 (DB-9), USB port, Ethernet 10/100Mbps
Control Panel: One Tri-color LED: Power (Green, Orange and Red), Function Key: FEED
Power: Auto Switching 100-240VAC, 50-60Hz
Environment: Operation temperature: 41°F to 104°F (5°C to 40°C) / Storage temperature: -4°F to 122°F (-20°C to 50°C)
Humidity: Operation: 30-85%, non-condensing / Storage: 10-90%, non-condensing.
Agency Approvals: CE(EMC), FCC Class A, CB, CCC
Dimension: Length: 10” (254 mm) / Height: 6.7” (170 mm) / Width: 8.8” (224 mm)
Weight: 5.5 lbs (2.5Kg) ,excluding consumables

Options:
USB Device + Parallel interfaces (factory install)
External label roll holder for 10” (250 mm) O.D. label rolls
External label rewinder
