Specifications
It is full automatic packing machineautomatic packaging machine
automatic palletizer robot
Application:
It is Automatic packing system , palletizing robot , automatic palletizer robot , Automatic Packing Machine, flour bagging line , automatic packing line system, palletizing robot flour packing line that applicable for packing granular or particulate materials such as chemistry, fertilizer, seeds, nuts, grain, rice, flour, wheat flour, cassava starch, starch, pellet, animal feed, urea, phosphate, PP, PE granules, powder, construction materials, building powder, wood pellets, bran pellets, fuel pellets, etc. And also the automatic robot palletizing machine and pallet stretch wrapping machine are optional for the completely automatic packaging stacking line. Equipped in factory production line for automatic filling bagging and robot stacking on pallets. automatic can filling production line palletizing robot
Main Component:
1. Automatic quantity-fixed balance
2.Automatic bag-supplying and weighing filling section
3. Optional section such as air compressor
4.Automatic bag-clamped section
5. Automatic belt conveyor
6.Automatic sewing or sealing machine
7. Automatic bag-backwards section
8. Automatic robot palletizing machine for option
9. Automatic online pallet stretch wrapping machine for option
10. Electrical PLC instrument control cabinet
Characteristic:
1. Picking bag, feeding bag, filling material, weighing, sewing or sealing bag, bag-backwards and bag transmission are finished completely automatically. Optional automatic palletizing, stretch wrapping.
2. Adopting PLC to guarantee the reliability of control
3. Adopting high-precision transducer and intelligent instrument to guarantee the accuracy and speed of weight
4. Adopting touch screen with trouble display and help system for easy operation.
5. Adopting imported pneumatic components features compact structure, reliable performance and convenient maintenance.
6. The sewing machine and sealing machine is an imported NEWLONG brand machine.
Main Technical Parameter:
Model: MZDP
Packing Scope: 5~10, 10~25, 25~50 (KG) (adjustable)
Weight Accuracy: ±0.2%FS
Packaging Material: Open mouth bag
Bag Size: 950×650mm(adjustable as per different weight )
Air Pressure: 0.6 (Mpa)
Air Consumption: 0.7 (m3/min)
Power: 8~16 (KW)
Total weight: 25000 (KG)
