Automatic Biomass Pellets Packing Line With Robot Palletizer

Specifications

Application:

It is automatic filling and packaging system,   automatic biomass pellets packing line with robot palletizer ,  15 kg foil bags automatic packing line  ,  Automated packing system, Automatic Packing Machine, automated packaging line, automated bagging palletizing machine, automated bagging packaging palletizing line, full automated packing line that applicable for packing granular or particulate materials such as wheat flour, maize meal, oat flour,  fodder, animal feed, mineral powder, ore fines, wood pellets, etc. automatic packing machine with CE, ISO9001-2008, CQC

And also the automatic robot palletizer and pallet stretch wrapping machine are optional for the complete automatic packing machine automatic packaging stacking and pallet stretch wrapping line. automatic packing machinery

Main Component:

1. Automatic quantity-fixed balance

2.Automatic bag-supplying and weighing filling section

3. Optional section such as air compressor

4.Automatic bag-clamped section

5. Automatic belt conveyor

6.Automatic sewing or sealing machine

7. Automatic bag-backwards section

8. Automatic robot palletizing machine for option

9. Automatic online pallet stretch wrapping machine for option

10. Electrical PLC instrument control cabinet

Characteristic:

1. Picking bag, feeding bag, filling material, weighing, sewing or sealing bag, bag-backwards and bag transmission are finished completely automatically. Optional automatic palletizing, pallet stretch wrapping.

2. Adopting PLC to guarantee the reliability of control

3. Adopting high-precision transducer and intelligent instrument to guarantee the accuracy and speed of weight

4. Adopting touch screen with trouble display and help system for easy operation.

5. Adopting imported pneumatic components features compact structure, reliable performance and convenient maintenance.

6. The sewing / sealing machine is imported NEWLONG brand machine from Japan.

Main Technical Parameter:

Model: MZDP , automatic packing machine system

Packing Scope: 5~10, 10~25, 25~50 (KG) (adjustable as per requirement)

Weight Accuracy: ±0.2%FS

Packaging Material: Open mouth bag

Bag Size: 950×650mm(adjustable as per different weight )

Air Pressure: 0.6 (Mpa)

Air Consumption: 0.7 (m3/min)

Power: 8~16 (KW)

Total weight: 25000 (KG)
