Specifications
Aluminum Stranded Wire and Aluminum Conductor Steel-reinforcedsells well in Europe, USA,Iran,India,Vietnam etc
Aluminum Stranded Wire and Aluminum Conductor Steel-reinforced
Application
The Aluminum Stranded Wire and Aluminum Conductor Steel-reinforced apply for electric transmission line overhead.
Specification and Produce range
No. |
Specification |
Name |
Cross-sectional area |
Standard |
1 |
LJ |
Aluminum stranded wire |
16~800 |
GB/T1179-1999 |
2 |
LGJ |
Aluminum conductor steel-reinforced |
10/2~800/100 |
|
3 |
LGJF |
Anticorrosive aluminum conductor steel-reinforced |
10/2~800/100 |
|
4 |
JL |
Aluminum stranded wire |
10~800 |
GB/T 1179-1999 |
5 |
JLHA2,JLHA1 |
Aluminum alloy stranded wire |
16~800 |
|
6 |
JL/G1A,JL/G1B,JL/G2A,JL/G2B,JL/G3A |
Aluminum conductor steel-reinforced |
16~800 |
|
7 |
JL/G1AF,JL/G2AF,JL/G3AF |
Anticorrosive aluminum conductor steel-reinforced |
16~800 |
|
8 |
JLHA2/G1A,JLHA2/G1B,JLHA2/G3A |
Aluminum alloy conductor steel-reinforced |
16~800 |
|
9 |
JLHA1/G1A,JLHA1/G1B,JLHA1/G3A |
Aluminum alloy conductor steel-reinforced |
16~800 |
|
10 |
JL/LHA2,JL/LHA1 |
Aluminum conductor aluminum alloy reinforced |
16~800 |
|
11 |
JL/LB1A |
Aluminum conductor aluminum coated steel-reinforced |
16~800 |
|
12 |
JLHA2/LB1A,JLHA1/LB1A |
Aluminum alloy conductor aluminum coated steel-reinforced |
16~800 |
|
13 |
JG1A,JG1B,JG2A,JG3A |
Steel stranded wire |
4~63 |
|
14 |
JLB1A,JLB1B,JLB2 |
Aluminum coated steel stranded wire |
4~200 |
Technical Data
Aluminum Stranded Wire
Nominal cross-sectional area mm2 |
Construction No. /Diameter mm |
Calculated cross-section mm2 |
Overall diameter mm |
D.C. resistance of conductor Ω/km |
Calculated tensile force N |
Appro. Weight kg/km |
Delivery length m |
16 |
7/1.70 |
15.89 |
5.1 |
1.802 |
2840 |
43 |
4000 |
25 |
7/2.15 |
25.41 |
6.4 |
1.127 |
4355 |
69 |
3000 |
35 |
7/2.50 |
34.36 |
7.5 |
0.8332 |
5760 |
94 |
2000 |
50 |
7/3.00 |
49.48 |
9.0 |
0.5786 |
7930 |
135 |
1500 |
... |
|||||||
400 |
37/3.70 |
397.83 |
25.9 |
0.07247 |
61150 |
1097 |
1000 |
500 |
37/4.16 |
502.90 |
29.1 |
0.05733 |
76370 |
1387 |
1000 |
630 |
61/3.63 |
631.30 |
32.6 |
0.04577 |
91940 |
1744 |
800 |
800 |
61/4.10 |
805.36 |
36.9 |
0.03588 |
115900 |
2225 |
800 |
GB/T1179-1999
Aluminum Stranded Wire
Specification |
Cross-sectional mm2 |
No. of single wire N |
Diameter |
Weight kg/km |
Rated tensile force kN |
D.C. resistance of conductor at 20℃ Ω/km |
|
|
Single wire mm |
Stranded conductor mm |
||||||
10 |
10 |
7 |
1.35 |
4.05 |
27 |
1.95 |
2.8633 |
16 |
16 |
7 |
1.71 |
5.12 |
43 |
3.04 |
1.7896 |
25 |
25 |
7 |
2.13 |
6.40 |
68 |
4.50 |
1.1453 |
40 |
40 |
7 |
2.70 |
8.09 |
109 |
6.80 |
0.7158 |
63 |
63 |
7 |
3.39 |
10.2 |
172 |
10.39 |
0.4545 |
100 |
100 |
19 |
2.59 |
12.9 |
274 |
17.00 |
0.2877 |
125 |
125 |
19 |
2.89 |
14.5 |
343 |
21.25 |
0.2302 |
160 |
160 |
19 |
3.27 |
16.4 |
439 |
26.40 |
0.1798 |
... |
|||||||
1120 |
1120 |
91 |
3.96 |
43.5 |
3093 |
179.20 |
0.0258 |
1250 |
1250 |
91 |
4.18 |
46.0 |
3452 |
200.00 |
0.0231 |
1400 |
1400 |
91 |
4.43 |
48.7 |
3866 |
224.00 |
0.0207 |
1500 |
1500 |
91 |
4.58 |
50.4 |
4143 |
240.00 |
0.0193 |
GB/T1179-1999
Aluminum Conductor steel-reinforced
|
Speci- fica- tion |
% Steel rate |
Area |
No. of wire |
Diameter of single wire |
Diameter |
Weight kg/km |
Rated tensile force |
20℃ D.C. resistance of conductor at 20℃ Ω/km |
||||||||||||
Al. |
St. |
Total |
Al. |
St. |
Al. |
St. |
Steel core |
Conductor |
JL/G1A |
JL/G1B |
JL/G2A |
JL/G2B |
JL/G3A |
|||||||
mm2 |
mm |
mm |
KN |
|||||||||||||||||
16 |
17 |
16 |
2.67 |
18.7 |
6 |
1 |
1.84 |
1.84 |
1.84 |
5.53 |
64 |
6.08 |
5.89 |
6.45 |
6.27 |
6.83 |
1.7934 |
|||
25 |
17 |
25 |
4.17 |
29.2 |
6 |
1 |
2.30 |
2.30 |
2.30 |
6.91 |
100 |
9.13 |
8.83 |
9.71 |
9.42 |
10.25 |
1.1478 |
|||
40 |
17 |
40 |
6.67 |
46.7 |
6 |
1 |
2.91 |
2.91 |
2.91 |
8.74 |
161 |
14.40 |
13.93 |
15.33 |
14.87 |
16.20 |
0.7174 |
|||
63 |
17 |
63 |
10.5 |
73.5 |
6 |
1 |
3.66 |
3.66 |
3.66 |
11.0 |
254 |
21.63 |
20.58 |
22.37 |
21.63 |
24.15 |
0.4555 |
|||
... |
||||||||||||||||||||
1000 |
4 |
1000 |
43.2 |
1043 |
72 |
7 |
4.21 |
2.80 |
8.41 |
42.1 |
3100 |
209.26 |
206.23 |
215.31 |
212.28 |
220.93 |
0.0289 |
|||
1120 |
4 |
1120 |
47.3 |
1167 |
72 |
19 |
4.45 |
1.78 |
8.90 |
44.5 |
3464 |
234.53 |
231.22 |
241.15 |
237.84 |
247.77 |
0.0258 |
|||
1120 |
8 |
1120 |
91.2 |
1211 |
84 |
19 |
4.12 |
2.47 |
12.4 |
45.3 |
3811 |
283.17 |
276.78 |
295.94 |
289.55 |
307.79 |
0.0258 |
|||
1250 |
4 |
1250 |
52.8 |
1303 |
72 |
19 |
4.70 |
1.88 |
9.40 |
47.0 |
3867 |
261.75 |
258.06 |
269.14 |
265.44 |
276.53 |
0.0231 |
|||
1250 |
8 |
1250 |
102 |
1352 |
84 |
19 |
4.35 |
2.61 |
13.1 |
47.9 |
4253 |
316.04 |
308.91 |
330.29 |
232.16 |
343.52 |
0.0232 |
|||
The data in above table also fit for anti-corrosive Aluminum conductor steel reinforced with the specification JFL/G1A,JFL/G2A,JFL/G3A.
